Western Digital Black SN750 2TB Gen3 NVMe Gaming Solid State Drive

GAMING HDD (with heatsink)
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:2TB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW):1200
Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
With Heatsink model no:WDS200T3XHC-00SJG0

Western Digital Black SN750 Gen3 NVMe Gaming Solid State Drive

GAMING HDD (with heatsink)
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:1TB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,470
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600
Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
With Heatsink model no: WDS100T3XHC-00SJG0

Western Digital Black SN750 500GB NVMe Gaming Solid State Drive

GAMING HDD (with heatsink)
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:500GB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300
Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
With Heatsink model no: WDS500G3XHC-00SJG0

Western Digital Black SN750 2TB NVMe Gaming Solid State Drive

GAMING HDD
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:2TB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW):1200
Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
Without Heatsink model no: WDS200T3X0C-00SJG0

Western Digital Black SN750 1TB NVMe Gaming Solid State Drive

GAMING HDD
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:1TB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600
Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
Without Heatsink model no: WDS100T3X0C-00SJG0

Western Digital Black SN750 NVMe Gaming Solid State Drive

GAMING HDD
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:500GB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300
Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
Without Heatsink model no: WDS500G3X0C-00SJG0

Western Digital Black SN750 NVMe 250GB Gaming Solid State Drive

GAMING HDD
Specifications:
Interface:PCIe Gen3 8Gb/s, up to 4 lanes
Formatted Capacity:250GB
Performance:
Sequential Read MB/s up to (Q=32, T=1):3,100
Sequential Write MB/s up to (Q=32, T=1):1,600
Random Read 4KB IOPS up to (Q=32, T=8):220K
Random Write 4KB IOPS up to (Q=32, T=8):180K
Endurance (TBW):200
Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW
Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g
Limited Warranty:5 years Warranty
Ordering Information:
Without Heatsink model no: WDS250G3X0C-00SJG0

Western Digital Purple 6TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 5400 RPM
model no:WD60PURZ
capcity:6TB
Cache:64mb
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 4TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 5400 RPM
model no:WD40PURZ
capacity:4TB
Cache:64mb
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 3TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 5400 RPM
model no:WD30PURZ
capacity:3TB
Cache:64mb
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 2TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 5400 RPM
model no:WD20PURZ
capacity:2TB
Cache:64mb
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 1TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 5400 RPM
model no:WD10PURZ
capcaity:1TB
Cache:64mb
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 14TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 7200 RPM
model:WD140PURZ
capciy:14TB
Cache:512
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 12TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 7200 RPM
model:WD121PURZ
capcity:12TB
Cache:256
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 7200 RPM
capcity:10tb
model:WD101PURZ
Cache:256
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 10TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 7200 RPM
model:WD102PURZ
capacity:10TB
Cache:256
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital Purple 8TB Surveillance Hard Drive

Features
Form Factor:3.5
Interface:SATA 6Gb/s
wd purple 7200 RPM
model no:WD82PURZ
capacity:8TB
Cache:256
Height (in./mm, max) 1.028/26.1
Length (in./mm, max) 5.787/147
Width (in./mm, ± .01 in.) 4/101.6
Limited Warranty:3 years Warranty

Western Digital WD WD2002FFSX 14TB Hard disk drive

Features

Capacity:2tb-14TB

2TB:WD2002FFSX (CMR)

3TB:WD30EFAX (SMR)WD30EFRX (CMR)

4TB:WD4003FFBX (CMR)

6TB:WD6003FFBX (CMR)

8TB:WD6003FFBX (CMR)

10TB:WD101KFBX (CMR)WD102KFBX (CMR)

12TB:WD121KFBX (CMR)

14TB:WD141KFGX (CMR)

Form Factor:3.5inch

Rotational speed (RPBM):5400

Interface:SATA 6GB/s

Limited Warranty:3 years

Western Digital WD WD20EFRX 14TB Hard disk drive

Features
Capacity:1tb-14TB
1TB:WD10EFRX (CMR)
2TB:WD20EFAX (SMR)WD20EFRX (CMR)
3TB:WD30EFAX (SMR)WD30EFRX (CMR)
4TB:WD40EFAX (SMR)WD40EFRX (CMR)
6TB:WD60EFAX (SMR)WD60EFRX (CMR)
8TB:WD80EFAX (CMR)WD8003FFBX (CMR)
10TB:WD100EFAX (CMR)WD101EFAX (CMR)
12TB:WD120EFAX (CMR)
14TB:WD140EFAX (CMR)
Form Factor:3.5inch
Rotational speed (RPBM):5400
Interface:SATA 6GB/s
Limited Warranty:3 years

Western Digital WD WD10JFCX 1TB Hard disk drive

Features

Capacity:1tb

Form Factor:2.5inch, 9.5mm

Rotational speed (RPM):5400

Interface:SATA 6GB/s

Limited Warranty:3 years

Model Numbers:1TB:WD10JFCX (CMR)

Western Digital WD WDS500G1R0A 500GB Hard disk drive

Capacity:500GB-4TB
Form Factor:2.5” /7mm
Interface:SATA 6 Gb/s
Limited Warranty:5 Years
Model Numbers:500GB:WDS500G1R0A
1TB:WDS100T1R0A
2TB:WDS200T1R0A
4TB:WDS400T1R0

Western Digital WD WDS768T1D0D Hard disk drive

Product Specification
Capacity:7.6TB
Model Number:WDS768T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):1.8K
Read IOPS (max, Rnd 4KiB):467K
Write IOPS (max, Rnd 4KiB):65K
Mixed IOPS (max, 70/30 R/W, 4KiB):187K
Latency (μs, 4KiB Random Read QD1, 99%):225
Maximum Petabytes Written:11.21

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Western Digital WD WWDS384T1D0D Hard disk drive

Product Specification
Capacity:3.84TB
Model Number:WWDS384T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):1.8K
Read IOPS (max, Rnd 4KiB):469K
Write IOPS (max, Rnd 4KiB):63K
Mixed IOPS (max, 70/30 R/W, 4KiB):174K
Latency (μs, 4KiB Random Read QD1, 99%):221
Maximum Petabytes Written:5.61

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Western Digital WD WDS192T1D0D 1 Point 92TB Hard disk drive

Product Specification
Capacity:1.92TB
Model Number:WDS192T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):2K
Read IOPS (max, Rnd 4KiB):472K
Write IOPS (max, Rnd 4KiB):63K
Mixed IOPS (max, 70/30 R/W, 4KiB):194K
Latency (μs, 4KiB Random Read QD1, 99%):208
Maximum Petabytes Written:2.8

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Western Digital WD WDS960G1D0D 96TB Hard disk drive

Product Specification
Capacity:96TB
Model Number:WDS960G1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3K
Write Throughput (max MiB/s, Seq 128KiB):1.1K
Read IOPS (max, Rnd 4KiB):413K
Write IOPS (max, Rnd 4KiB):44K
Mixed IOPS (max, 70/30 R/W, 4KiB):111K
Latency (μs, 4KiB Random Read QD1, 99%):210
Maximum Petabytes Written:1.4

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Western Digital WD Black WD5003AZEX 6TB Hard disk drive

WD 3.5 INCH,
Capacity:500GB - 6TB
Interface:SATA 6Gb/s
Limited Warranty:5 years
RPM Class:7200
Model Numbers: 500gb:WD5003AZEX (CMR)
1TB:WD1003FZEX (CMR)
2TB:WD2003FZEX (CMR)
4TB:WD4005FZBX (CMR)
6TB:WD6003FZBX (CMR)
colour: black

Western Digital WD Black WD10SPSX 1TB Hard disk drive

WD 2.5 INCH,9.5MM
Capacity:1TB
Interface:SATA 6Gb/s
Limited Warranty:5 years
RPM Class:7200
Model Numbers:WD10SPSX (SMR)
colour: black

Western Digital WD Black WD2500LPLX 1TB Hard disk drive

WD 2.5 INCH,7MM
Capacity:250GB - 500GB
Interface:SATA 6Gb/s
Limited Warranty:5 years
RPM Class:7200
Model Numbers:250GB WD2500LPLX (CMR)
320GB: WD3200LPLX (CMR)
500GB:WD5000LPLX (CMR)
colour: black

Western Digital WDS200T3XHC 00SJG0 2TB Hard disk drive

Formatted Capacity:2TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW):1200

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS200T3XHC-00SJG0

Western Digital WDS100T3XHC 00SJG0 1TB Hard disk drive

Formatted Capacity:1TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,470
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS100T3XHC-00SJG0

Western Digital WDS500G3XHC 00SJG0 500GB Hard disk drive

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS500G3XHC-00SJG0

Western Digital WDS500G3XHC 00SJG0 500GB Hard disk drive

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS500G3XHC-00SJG0

Western Digital WDS200T3X0C 00SJG0 2TB Hard disk drive

Formatted Capacity:2TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW)1,200

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS200T3X0C-00SJG0

Western Digital WDS100T3X0C 00SJG0 1TB Hard disk drive

Formatted Capacity:1TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS100T3X0C-00SJG0

Western Digital WDS500G3X0C 00SJG0 500GB Hard disk drive

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW)4:300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS500G3X0C-00SJG0

Western Digital WDS250G3X0C 00SJG0 250GB Hard disk drive

Formatted Capacity:250GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,100
Sequential Write MB/s up to (Q=32, T=1):1,600
Random Read 4KB IOPS up to (Q=32, T=8):220K
Random Write 4KB IOPS up to (Q=32, T=8):180K
Endurance (TBW)4:200

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS250G3X0C-00SJG0

Seagate Backup Plus Slim STDR2000301 Portable Drive

Model: STDR2000301
Capacity: 2TB
Interface: USB 3.0
Colour: Silver
Height: 12.1
Length: 113.5 mm
Width: 76 mm
Warranty: 3 year limited warranty

Seagate Backup Plus Slim 2TB Portable External Hard Drive

Model: STDR2000309
Capacity: 2TB
Interface: USB 3.0
Colour: Rose Gold
Height: 12.1
Length: 113.5 mm
Width: 76 mm
Warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN2000401 Portable External Hard Drive

Model: STHN2000401
capacity: 2 TB
Interface:USB 3.0
Colour: Silver
Height: 11.7
Length: 114.8 mm
width: 78 mm
Warranty: 3 year limited warranty

Seagate Backup Plus STDR2000303 Portable External Hard Drive

Model: STDR2000303
Capacity: 2TB
Interface: USB 3.0
Colour: Red
Height: 12.1
Length: 113.5 mm
width: 76 mm
Warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH2000301 External Hard Drive

Model: STHH2000301
Capacity: 2TB
Interface: USB 3.0
Colour: White
Height: 11.7
Length: 114.8 mm
width: 78 mm
Warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN2000404 External Hard Drive

Model: STHN2000404
Capacity: 2 TB
Interface: USB 3.0
Colour: Gold
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN2000403 Portable External Hard Drive

Model: STHN2000403
Capacity: 2 TB
interface: USB 3.0
Colour: Red
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Slim STEH2000300 Portable Drive

Model: STEH2000300
Capacity: 2 TB
Interface: USB 3.0
Colour: Platinum
Height: 9.6
Length: 113.5 mm
width: 76 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Slim STEH2000301 Portable Drive

Model: STEH2000301
Capcity: 2 TB
Colour: Gold
Interface: USB 3.0
Height: 9.6
Length: 113.5 mm
width: 76 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN2000402 Portable External Hard Drive

Model: STHN2000402
Capacity: 2 TB
Interface: USB 3.0
Colour: Light Blue
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN2000405 External Hard Drive

Model: STHN2000405
capacity: 2 TB
Interface: USB 3.0
Colour: Rose Gold
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH2000400 Portable External Hard Drive

Model: STHH2000400
Capacity: 2 TB
Interface: USB 3.0
Colour: Black
Height: 11.7
length: 114.8 mm
width: 78 mm
warranty: 2 year limited warranty

Seagate Backup Plus Slim STHN2000406 External Hard Drive

Model: STHN2000406
Capacity: 2 TB
Interface: USB 3.0
Colour: Space Grey
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STDR2000300 Portable Drive

Model: STDR2000300
Capacity: 2 TB
Interface: USB 3.0
Colour: Black
Height: 12.1
Length: 113.5 mm
width: 76 mm
warranty: 3 year limited warranty

Seagate STHN2000400 Backup Plus Slim External Hard Drive

Model: STHN2000400
Capacity: 2 TB
Interface: USB 3.0
Colour: Black
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH2000402 Portable External Hard Drive

Model: STHH2000402
Capacity: 2 TB
Interface: USB 3.0
Colour: White
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 2 year limited warranty

Seagate Backup Plus Ultra Touch STHH2000300 External Hard Drive

Model: STHH2000300
Capacity: 2 TB
Interface: USB 3.0
Colour: Black
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH1000402 Portable External Hard Drive

Model: STHH1000402
Capacity: 1 TB
Interface: USB 3.0
Colour: White
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 2 year limited warranty

Seagate Backup Plus Slim STHN1000402 Portable External Hard Drive

Model: STHN1000402
Capacity: 1 TB
Interface: USB 3.0
Colour: Light Blue
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH1000301 External Hard Drive

Model: STHH1000301
Capacity: 1 TB
Interface: USB 3.0
Colour: White
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN1000404 External Hard Drive

Model: STHN1000404
Capacity: 1 TB
Interface: USB 3.0
Colour: Gold
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Slim STEH1000300 Portable Drive

Model: STEH1000300
Capacity: 1 TB
Interface: USB 3.0
Colour: Platinum
Height: 9.6
Length: 113.5 mm
width: 76 mm
warranty: 3 year limited warranty

Seagate Backup Plus Ultra Touch STHH1000400 Portable External Hard Drive

Model: STHH1000400
Capacity: 1 TB
Interface: USB 3.0
Colour: Black
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 2 year limited warranty

Seagate Backup Plus Slim STDR1000300 Portable External Hard Drive

Model: STDR1000300
Capacity: 1 TB
Interface: USB 3.0
Colour: Black
Height: 12.1
Length: 113.5 mm
width: 76 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STDR1000302 Portable Drive

Model: STDR1000302
Capacity: 1 TB
Interface: USB 3.0
Colour: Blue
Height: 12.1
Length: 113.5 mm
width: 76 mm
warranty:3 year limited warranty

Seagate Backup Plus Ultra Slim STEH1000301 External Hard Drive

Model: STEH1000301
Capacity: 1 TB
Interface: USB 3.0
Colour: Gold
Height: 9.6
Length: 113.5 mm
width: 76 mm
warrantty: 3 year limited warranty

Seagate Backup Plus Slim STHN1000400 Portable External Hard Drive

Model: STHN1000400
Capacity: 1 TB
Interface:USB 3.0
Colour: Black
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus STDR1000301 Portable Drive

Model: STDR1000301
Capacity: 1 TB
colour: Silver
Interface:USB 3.0
Height: 12.1
Length: 113.5 mm
width: 76 mm
warranty:3 year limited warranty

Seagate Backup Plus Slim STHN1000403 Portable External Hard Drive

Model: STHN1000403
capacity: 1 TB
colour: Red
Interface: USB 3.0
Height: 11.7
Length: 114.8 mm
width: 78 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STDR1000303 External Hard Drive

Model: STDR1000303
Capacity: 1TB
Interface: USB 3.0
Colour: Red
Height: 12.1
Length: 113.5 mm
Width: 76 mm
warranty: 3 year limited warranty

Seagate Backup Plus Slim STHN1000401 External Hard Drive

Model: STHN1000401
Capacity: 1TB
Interface: USB 3.0
Colour: Silver
Height: 11.7
Length: 114.8 mm
Width: 78 mm
Warranty: 3 year limited warranty

Seagate 1TB Backup Plus Slim External Hard Drive

Model: STHN1000405
Capacity: 1TB
Interface: USB 3.0
Colour: Space Grey
Height: 11.7
Length: 114.8 mm
Width: 78 mm
Warranty: 3 year limited warranty

Seagate 1TB Backup Plus Ultra Touch Portable External Hard Drive

Model: STHH1000300
Capacity: 1TB
Interface: USB 3.0
Colour: Black
Height: 11.7
Length: 114.8 mm
Width: 78 mm
Warranty:3 year limited warranty

LaCie 5TB USB 3 point 1 Type C Mobile Drive

Modal: LaCie Mobile Drive 5TB STHG5000402

warranty: 2-year limited warranty

Sleek Design. Lavish Space.

Like an airy loft or vast landscape, LaCie Mobile Drive articulates the

beauty and importance of premium space.

With up to 5 TB of capacity, there’s room for photos, playlists, docs and

more. And with Mac, Windows, USB-C, and USB 3.0 compatibility,

access is easy. One-click or automatic backup makes file storage smooth,

and our 30th anniversary diamond cut design has an edge like no other.

More Wonder. Less Wondering.

Wherever life takes you, whichever laptops and devices you opt for,

LaCie Mobile Drive is compatible enough to keep up.

Works with Mac and Windows.

Connect to modern and future laptops via reversible USB-C.1

Connect to legacy laptops via USB 3.0 to USB-C.

More Capacity for More Memories

When it comes to our digital lives, not much tops the affection we have for

photos and videos. And these memories add up fast. LaCie Mobile Drive

offers up to 5 TB of massive on-the-go space for everything worth storing

and backing up. Even music, movies, and personal documents.

There to help you is LaCie Toolkit — easy-to-use software for one-click

backups, scheduled automatic backups, and even folder mirroring across

multiple devices.

Keep up to 500K high-resolution photos.2

Store up to 165 hours of videos.3

Fit In. Stand Out.

Sandblast finish in space grey or moon silver to complement

Macbooks.

All-aluminium build feels light yet solid.

Diamond-cut edges reveal tone and texture.

Compact, it slips easily into your bag.

1 To achieve full interface bandwidth, connect the product to a USB-C port on a computer

or device.

2 Based on the average image size of digital cameras (10 MB)

3 On average, 1 hour of 4K 30fps compressed footage creates 30 GB of data.

EXTERNAL PORTABLE HARD DRIVE

Specifications

Capacity 2 TB and below Product Dimensions Box Dimensions Master Carton Dimensions Pallet Dimensions

Length (in/mm) 0.393 in/10 mm 1.358/34.5 mm 9.488 in/241 mm 47.992 in/1,219 mm

Width (in/mm) 3.456 in/87.8 mm 4.724 in/120 mm 6.968 in/177 mm 40.118 in/1,019 mm

Height (in/mm) 4.787 in/121.6 mm 7.204 in/183 mm 7.362 in/187 mm 37.401 in/950 mm

Weight (lb/kg) 0.440 lb/0.2 kg 0.661 lb/0.3 kg 6.834 lb/3.1 kg 729.509 lb/330.9 kg

Capacity 4 TB and above Product Dimensions Box Dimensions Master Carton Dimensions Pallet Dimensions

Length (in/mm) 0.787 in/20 mm 1.811 in/46 mm 9.921 in/252 mm 47.992 in/1219 mm

Width (in/mm) 3.590 in/91.2 mm 4.724 in/120 mm 7.716 in/196 mm 40.118 in/1,019 mm

Height (in/mm) 4.881 in/124 mm 7.204 in/183 mm 8.070 in/205 mm 37.401 in/950 mm

Weight (lb/kg) 0.881 lb/0.4 kg 1.102 lb/0.5 kg 8.818 lb/4 kg 917.123 lb/416 kg

Quantities

Boxes per Master Carton 10 (2 TB and below), 8 (4 TB and above)

Master Cartons per Pallet 96

Pallet Layers 4

System Requirements

Computer with a USB-C, USB 3.0 or USB 2.0 port

Latest version of Mac OS 10.12 or later / Latest version of Windows 10 or later

Minimum free disk space: 600 MB recommended

What's Included

LaCie Mobile Drive

USB-C (USB 3.1 10 Gb/s) cable

USB-C to USB-A cable

Quick Installation Guide

Region Model Number Capacity Colour

Limited Warranty

(years)

UPC Code EAN Code Multi-Pack UPC Notes

WW STHG1000400 1TB Moon Silver 2 763649130513 3660619404650 10763649130510 —

WW STHG2000400 2TB Moon Silver 2 763649130537 3660619404674 10763649130534 —

WW STHG2000402 2TB Space Gray 2 763649130612 3660619404759 10763649130619 Apple only

WW STHG4000400 4TB Moon Silver 2 763649130551 3660619404698 10763649130558 —

WW STHG4000402 4TB Space Gray 2 763649130636 3660619404773 10763649130633 Apple only

WW STHG5000400 5TB Moon Silver 2 763649130575 3660619404711 10763649130572 —

WW STHG5000402 5TB Space Gray 2 763649130650 3660619404797 10763649130657 Apple only

LaCie 5TB Mobile External Hard Drive

LaCie Mobile Drive 5 TB
Modal no: STHG5000400
warranty: 2-year limited warranty

Sleek Design. Lavish Space.
Like an airy loft or vast landscape, LaCie Mobile Drive articulates the
beauty and importance of premium space.
With up to 5 TB of capacity, there’s room for photos, playlists, docs and
more. And with Mac, Windows, USB-C, and USB 3.0 compatibility,
access is easy. One-click or automatic backup makes file storage smooth,
and our 30th anniversary diamond cut design has an edge like no other.
More Wonder. Less Wondering.
Wherever life takes you, whichever laptops and devices you opt for,
LaCie Mobile Drive is compatible enough to keep up.
Works with Mac and Windows.
Connect to modern and future laptops via reversible USB-C.1
Connect to legacy laptops via USB 3.0 to USB-C.
More Capacity for More Memories
When it comes to our digital lives, not much tops the affection we have for
photos and videos. And these memories add up fast. LaCie Mobile Drive
offers up to 5 TB of massive on-the-go space for everything worth storing
and backing up. Even music, movies, and personal documents.
There to help you is LaCie Toolkit — easy-to-use software for one-click
backups, scheduled automatic backups, and even folder mirroring across
multiple devices.
Keep up to 500K high-resolution photos.2
Store up to 165 hours of videos.3
Fit In. Stand Out.
Sandblast finish in space grey or moon silver to complement
Macbooks.
All-aluminium build feels light yet solid.
Diamond-cut edges reveal tone and texture.
Compact, it slips easily into your bag.
1 To achieve full interface bandwidth, connect the product to a USB-C port on a computer
or device.
2 Based on the average image size of digital cameras (10 MB)
3 On average, 1 hour of 4K 30fps compressed footage creates 30 GB of data.

EXTERNAL PORTABLE HARD DRIVE
Specifications
Capacity 2 TB and below Product Dimensions Box Dimensions Master Carton Dimensions Pallet Dimensions
Length (in/mm) 0.393 in/10 mm 1.358/34.5 mm 9.488 in/241 mm 47.992 in/1,219 mm
Width (in/mm) 3.456 in/87.8 mm 4.724 in/120 mm 6.968 in/177 mm 40.118 in/1,019 mm
Height (in/mm) 4.787 in/121.6 mm 7.204 in/183 mm 7.362 in/187 mm 37.401 in/950 mm
Weight (lb/kg) 0.440 lb/0.2 kg 0.661 lb/0.3 kg 6.834 lb/3.1 kg 729.509 lb/330.9 kg
Capacity 4 TB and above Product Dimensions Box Dimensions Master Carton Dimensions Pallet Dimensions
Length (in/mm) 0.787 in/20 mm 1.811 in/46 mm 9.921 in/252 mm 47.992 in/1219 mm
Width (in/mm) 3.590 in/91.2 mm 4.724 in/120 mm 7.716 in/196 mm 40.118 in/1,019 mm
Height (in/mm) 4.881 in/124 mm 7.204 in/183 mm 8.070 in/205 mm 37.401 in/950 mm
Weight (lb/kg) 0.881 lb/0.4 kg 1.102 lb/0.5 kg 8.818 lb/4 kg 917.123 lb/416 kg

Quantities
Boxes per Master Carton 10 (2 TB and below), 8 (4 TB and above)
Master Cartons per Pallet 96
Pallet Layers 4

System Requirements
Computer with a USB-C, USB 3.0 or USB 2.0 port
Latest version of Mac OS 10.12 or later / Latest version of Windows 10 or later
Minimum free disk space: 600 MB recommended

What's Included
LaCie Mobile Drive
USB-C (USB 3.1 10 Gb/s) cable
USB-C to USB-A cable
Quick Installation Guide
Region Model Number Capacity Colour
Limited Warranty
(years)
UPC Code EAN Code Multi-Pack UPC Notes
WW STHG1000400 1TB Moon Silver 2 763649130513 3660619404650 10763649130510 —
WW STHG2000400 2TB Moon Silver 2 763649130537 3660619404674 10763649130534 —
WW STHG2000402 2TB Space Gray 2 763649130612 3660619404759 10763649130619 Apple only
WW STHG4000400 4TB Moon Silver 2 763649130551 3660619404698 10763649130558 —
WW STHG4000402 4TB Space Gray 2 763649130636 3660619404773 10763649130633 Apple only
WW STHG5000400 5TB Moon Silver 2 763649130575 3660619404711 10763649130572 —
WW STHG5000402 5TB Space Gray 2 763649130650 3660619404797 10763649130657 Apple only

LaCie 4TB Mobile USB C External Hard Drive

LaCie Mobile Drive 4TB

Modal no: STHG4000402
