• Cost-effective Wi-Fi 6 hospitality access points provide up to 1.5 Gbps maximum combined data rate with a range of connectivity options for venues such as hotels, residence halls, and remote offices.
• The AP provides supports for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
• The AP provides IoT-ready Bluetooth 5 and Zigbee support.
• Dynamic Segmentation and policy enforcement firewalls (PEF) automatically enforce consistent policies across all networks, enhancing user and device security.
• Zero Touch Provisioning that provides ease of implementation in branch offices and remote sites, without on-site technical expertise.
• You can customize deployment with optional desktop stand and models that offer choice of wired connectivity, USB, and PoE out support.

Certifications: Bluetooth SIG
Ethernet Alliance (PoE)
Wi-Fi Alliance:
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6 (ax)
WPA, WPA2 and WPA3- Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Agile Multiband
Passpoint (Release 2)
Wi-Fi CERTIFIED Location (HPE AP-505H Only)

Regulatory:
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-503H: Two integrated semi-directional antennas for 2x2 MIMO with peak single antenna gain of 2.5 dBi in 2.4 GHz and 5.6 dBi in 5 GHz.
AP 505H: Two integrated semi-directional antennas for 2x2 MIMO with peak single antenna gain of 5.2 dBi in 2.4 GHz and 5.4 dBi in 5 GHz.

Ports: USB 2.0 host interface (type A connector)
Serial console interface (proprietary, micro-B USB physical jack)

AP-503H:
E0: Ethernet wired network port (RJ-45);
E1-E2: Two Ethernet wired network ports (RJ45)

AP-505H:
E0: HPE Smart Rate RJ-45 port
E1-E4: Four Ethernet wired network ports (RJ45)

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: 50W max

Radio coverage: 5 GHz radio: Two spatial stream (SU/MU) MIMO for up to 1.2 Gbps wireless data rate (HE80)
2.4 GHz radio: Two spatial stream (SU/MU) MIMO for up to 287 Mbps wireless data rate (HE20)

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 360 gm (0.8 lb)

Dimensions: 150 x 86 x 47 mm (5.9 x 3.4 x 1.9 in)

• Unlock the 6 GHz band to deliver up to 1200 MHz additional capacity and up to 3.6 Gbps combined peak datarate.
• Up to seven 160 MHz channels in 6 GHz support low-latency, bandwidth-hungry applications such as high-definition video and augmented reality/virtual reality applications.
• Software programable, dual-radio operating modes deliver cost-effective coverage across any two of the three Wi-Fi 6E bands: 2.4 GHz, 5 GHz, 6 GHz with full tri-band coverage in multi-AP deployments.
• Low power consumption enables unrestricted operation from an 802.3af (Class 3) PoE source1.
• Built-in GPS receivers and fine time measurement allow APs to automatically locate themselves and serve as reference points for accurate indoor location measurements.
• Offered as optional eco-friendly 10-pack.

Certifications: UL2043 plenum rating;
Bluetooth SIG;
Ethernet Alliance (PoE, PD device, Class 4);
Wi-Fi Alliance (WFA): Wi-Fi CERTIFIED a, b, g, n, ac, Wi-Fi CERTIFIED 6E (ax, 6 GHz), WPA, WPA2 and WPA3 Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE), WMM, WMM-PS, W-Fi Agile Multiband, Wi-Fi CERTIFIED Location™

Input voltage: The AP supports direct DC power and Power over Ethernet (PoE) on port E0

Regulatory: AP-615 (all models): APIN0615
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-615: Integrated downtilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 2.8 dBi in 2.4 GHz, 4.5 dBi in 5 GHz and 4.5 dBi in 6 GHz.

Connectivity, standard: Wi-Fi 6E (802.11ax)

Ports:
E0: Ethernet wired network ports (RJ-45)
DC power interface: 12 Vdc (nominal, +/- 5%)
USB 2.0 host interface (Type A connector)
Bluetooth Low Energy (BLE5.0) and Zigbee (802.15.4) radio
Visual indicators (four multi-color LEDs)
Reset button: factory reset, LED mode control (normal/off)
Serial console interface (proprietary, micro-B USB physical jack)
Kensington security slot

Mounting: A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately); see the 610 Series ordering guide for details.

Power consumption: Maximum (worst-case) power consumption:
DC powered:12.5W/18.2W
POE powered: 14.7W/20.9W

Radio coverage: Indoor, dual-radio/tri-band 2.4 GHz, 5 GHz and 6 GHz (dual concurrent) 802.11ax 2x2 MIMO

Warranty: Limited lifetime warranty. See the warranty duration guide.

Weight: 0.72 kg (1.59 lb)

Dimensions: 5.1 x 20.1 x 18.3 x cm (2 x 7.9 x 7.2 in)

• Three radios to extend the benefits of Wi-Fi 6E to the 6 GHz band –unlocking up to 1200 MHz of spectrum.
• Wider channels and less interference to deliver faster speeds for ow-latency, bandwidth-hungry applications like high-definition video and augmented reality/virtual reality.
• Unique filtering capabilities to mitigates gaps in coverage and help minimize interference between the 5 GHz and 6 GHz bands.
• High availability with hitless failover for Ethernet and power to help ensure business continuity.
• Automated notification and easy deployment of 6 GHz regulatory tables to allow countries to take advantage of Wi-Fi 6E once it is approved in country.

Certifications: UL2043 plenum rating; Wi-Fi Alliance; Wi-Fi CERTIFIED a, b, g, n, ac; Wi-Fi CERTIFIED 6E (ax, 6GHz); WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE); WMM, WMM-PS, Wi-Fi Vantage, W-Fi Agile Multiband; Wi-Fi Location; Passpoint (release 2); Bluetooth SIG; Ethernet Alliance (POE, PD device, class 5)

Input voltage: 12 Vdc (+/- 5%) or 48 Vdc (nominal) PoE

Regulatory:
FCC/ISED; CE Marked; RED Directive 2014/53/EU; EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU; UL/IEC/EN 60950; IEC/EN 62368-1; EN 60601-1-1, EN60601-1-2
For more country-specific regulatory information and approvals, contact see your HPE Aruba Networking representative.

Regulatory considerations for AP-634:
The AP-634 will be offered in countries where there is an existing or clear and defined path to allow operation of 6 GHz radios with external connectorized antennas, either as a low power indoor or standard power product. Please contact your HPE Aruba Networking representative to confirm (existing or planned) availability for the country where the AP will be deployed.

Wi-Fi antenna:
AP-634 (external antenna support): Two sets of two (female) RP-SMA connectors for external antennas (A0 & A1 corresponding with radio chains 0 and 1 for the 2.4 GHz and 5 GHz radios, and B0 and B1 corresponding with radio chains 0 and 1 for the 6 GHz radio). Worst-case internal loss between radio interface and external antenna connectors: 1.0 dB in 2.4 GHz, 1.0 dB in 5 GHz and 1.0 dB in 6 GHz.

AP-635 (internal antenna): Integrated downtilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.6 dBi in 2.4 GHz, 7.0 dBi in 5 GHz and 6.3 dBi in 6 GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 to 40 degrees.
Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the combined, average pattern is 2.9 dBi in 2.4 GHz, 4.9 dBi in 5 GHz and 4.3 dBi in 6 GHz.

Heat dissipation: 66.3 BTU/hr worst case (PoE powered), 57.9 BTU/hr worst case (DC)

Connectivity, standard: Wi-Fi 6E (IEEE 802.11ax)
WLAN: tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11ax 2x2 MIMO
Bluetooth Low Energy (BLE5.0) and Zigbee (802.15.4) radio

Ports: E0, E1: Two Ethernet wired network ports (RJ-45), auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX
DC power interface
USB 2.0 host interface (Type A connector)
Visual indicators (four multi-color LEDs)
Reset button: factory reset, LED mode control

Mounting: A mounting bracket has been preinstalled on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately). Optional mounting kits available, see the ordering guide.

Power consumption: 23.8 W worst case (POE powered), 20.7 W worst case (DC). Excludes power needed to supply up to 5W to an attached USB device.

Radio coverage: Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11ax 2x2 MIMO

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 1300g (2.86lb)

Dimensions: 220mm x 220mm x 50mm (8.66in x 8.66in x 1.96in)

• AI-powered Wi-Fi 7 access points ideal for the most demanding enterprise, healthcare, LPV, education, retail, and industrial IoT deployments.
• Three 4x4 MIMO radios provide comprehensive tri?band coverage across 2.4 GHz, 5 GHz, and 6 GHz for up to 18.7 Gbps maximum aggregate data rate.
• High availability with dual 10 Gbps wired ports for redundant Ethernet and power, as well as the ability to combine (sum) power from both ports.
• High density IoT support with two integrated1 Bluetooth 5.4 and 802.15.4 radios for Zigbee support and two USB port extensions.
• Built-in GNSS receiver, barometric pressure sensor, and intelligent software enable Access Points to self locate and act as reference points for accurate indoor location measurements.
• Patented Ultra Tri-band (UTB) filtering enhances use of 5 GHz and 6 GHz bands.

Certifications: Bluetooth SIG
Ethernet Alliance (PoE, PD device, Class 6)
UL2043 plenum rating
Wi?Fi Alliance (WFA)
Wi?Fi CERTIFIED a, b, g, n, ac, 6, 7
WPA, WPA2 and WPA3- Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM?PS, W?Fi Agile Multiband

Regulatory:
FCC/ISED;
CE Marked;
RED Directive 2014/53/EU;
EMC Directive 2014/30/EU;
Low Voltage Directive 2014/35/EU;
UL/IEC/EN 60950;
IEC/EN 62368?1;
EN 60601?1?1;
EN60601?1?2
For more country?specific regulatory information and approvals, please see your HPE Aruba Networking representative.

Wi-Fi antenna: AP?754: Two sets of four (female) RP?SMA connectors for external antennas (A0 through A3 corresponding with radio chains 0 through 3 for the 2.4 GHz and 5 GHz radios, and B0 through B3 corresponding with radio chains 0 through 3 for the 6 GHz radio). Worst?case internal loss between radio interface and external antenna connectors: 1.1 dB in 2.4 GHz, 1.8 dB in 5 GHz, and 2.8 dB in 6 GHz.

AP?755: Integrated down tilt omni?directional antennas for 4x4 MIMO with peak antenna gain of 5.3 dBi in 2.4 GHz, 6.0 dBi in 5 GHz (5.8 dBi in dual?5 GHz mode) and 6.0 dBi in 6 GHz (5.9 dBi in dual?6 GHz mode). Built?in antennas are optimized for horizontal ceiling mounted orientation of the AP. The down tilt angle for maximum gain is roughly 30 to 40 degrees.

Connectivity, standard: Wi-Fi 7 (802.11be)

Ports: E0, E1: Two Ethernet wired network ports (RJ?45);
U0, U1: Two USB 2.0 host interface (Type A connector);
Serial console interface (proprietary, micro?B USB physical jack);
Kensington security slot;

Mounting: A mounting bracket has been preinstalled on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately). Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst case) power consumption (without/with USB devices attached):
DC powered: 35W/46W
PoE powered: 40W/51W
This assumes that up to 10W is supplied to the attached USB device(s)

Maximum (worst?case) power consumption in idle mode: 14W/25W (DC) or 12W/23W (PoE)
Maximum (worst?case) power consumption in deep?sleep mode: 2.4W (DC) or 3.5W (PoE)

Radio coverage: AP type: Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11be 4x4 MIMO

Warranty: Limited lifetime warranty.

• Wi-Fi 7 access points ideal for enterprises, healthcare, LPV, education, retail, and industrial IoT deployments.
• Comprehensive tri?band coverage across 2.4 GHz, 5 GHz, and 6 GHz delivers up to 9.3 Gbps maximum aggregate data rate.
• Patented Ultra Tri-band (UTB) filtering improves the use of 5 GHz and 6 GHz bands.
• High density IoT support with two integrated Bluetooth 5.4 and 802.15.4 radios for Zigbee support and two USB port extensions.
• Built-in GNSS receiver, barometric pressure sensor, and intelligent software enable Access Points to self locate and act as reference points for accurate indoor location measurements.
• High availability with dual 5 Gbps ports for redundant Ethernet and power.

Certifications: Bluetooth SIG; Ethernet Alliance (PoE, PD device, Class 5); UL2043 plenum rating;
Wi?Fi Alliance (WFA):
Wi?Fi CERTIFIED a, b, g, n, ac, 6, 7
WPA, WPA2 and WPA3
Enterprise with CNSA option
Personal (SAE), Enhanced
Open (OWE)
WMM, WMM?PS, W?Fi Agile Multiband

Input voltage: PoE?PD: 48Vdc (nominal) 802.3at/bt PoE (Class 4 or higher);
DC power interface: 12 VDC(nominal, +/? 5%), accepts 2.1mm/5.5mm center?positive circular plug with 9.5mm length

Regulatory: FCC/ISED; CE Marked; RED Directive 2014/53/EU; EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU; UL/IEC/EN 60950; IEC/EN 62368?1; EN 60601?1?1, EN60601?1?2

Wi-Fi antenna: AP?734: Two sets of two (female) RP?SMA connectors for external antennas (A0 and A1 corresponding with radio chains 0 and 1 for the 2.4 GHz and 5 GHz radios, and B0 and B1 corresponding with radio chains 0 and 1 for the 6 GHz radio). Worst?case internal loss between radio interface and external antenna connectors: 0.8 dB in 2.4 GHz, 1.2 dB in 5 GHz, and 1.2 dB in 6 GHz.

AP?735: Integrated down-tilt omni?directional antennas for 2x2 MIMO with peak antenna gain of 5.1dBi in 2.4 GHz, 5.5dBi in 5 GHz (5.2dBi in dual?5 GHz mode) and 5.3dBi in 6 GHz (5.2dBi in dual?6 GHz mode). Built?in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 to 40 degrees.

Connectivity, standard: Wi-Fi 7 (IEEE 802.11be)

Ports: E0, E1: Two Ethernet wired network ports (RJ?45);
U0, U1: Two USB 2.0 host interface (Type A connector);
Kensington security slot;
Serial console interface (proprietary, micro?B USB physical jack);
Reset button: Factory reset, LED mode control (normal/off);
Visual indicators (four multi?color LEDs) for System (1x) and Radio (3x) status

Mounting: A mounting bracket has been preinstalled on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately). Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst case) power consumption (without/with USB devices attached):
DC powered: 20W/31W.
PoE powered: 24W/36W.
Notes:
This assumes that up to 10W is supplied to the attached USB device(s).
Maximum (worst?case) power consumption in idle mode: 8W/19W (DC) or 12W/24W (PoE).
Maximum (worst?case) power consumption in deep?sleep mode: 1.5W (DC) or 2.0W (PoE).

Radio coverage: AP type: Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11be 2x2 MIMO

Warranty: Limited lifetime warranty.

• Outdoor Wi-Fi 6 access points provide maximum aggregate data rate of 2.97 Gbps.
• Purpose built to survive in the harshest outdoor environments and extreme temperatures (-40 to +65?C) with IP66/67 ratings.
• Flexible connectivity and power options with support for 5 Gbps multi-gigabit Ethernet ports and 802.3bt Class 6 power or AC power.
• 1 Bluetooth and 802.15.4/Zigbee radios with high power to meet Industrial IoT requirements.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.

Certifications: Wi-Fi Alliance
Bluetooth SIG
Ethernet Alliance (E0, PoE PD device, class 6; E2, PoE PSE device, class 3)

Input voltage: IEEE 802.3 at PoE, or direct AC power (via optional power supply)
AC power interface: 110-240V (requires AP-AC-MLX power connector kit)

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
IEC 60950-22
IEC/EN60601-1-2
EN 50155

Wi-Fi antenna: AP-584: Four Nf connectors for external dual band antennas (WIFI0 through WIFI3, corresponding with radio chains 0 through 3), and one Nf connector for BT (includes 5 dB 2.4 GHz omni-directional antenna).
AP-585: Four integrated dual-band omni-directional antennas for 4x4 MIMO with peak antenna gain of 4.4 dB in 2.4 GHz and 5.8 dB in 5 GHz.
AP-587: Four integrated 90°H x 90°V dual-band directional antennas for 4x4 MIMO with peak antenna gain of 5.8 dB in 2.4 GHz and 6.6 dB in 5 GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: The AP supports direct AC power and Power over Ethernet (802.3bt PoE; on port E0 only).
When both AC and PoE power sources are available, AC power takes priority over PoE.
Power sources are sold separately.

Radio coverage: Outdoor-hardened, Wi-Fi 6 dual radio, 5 GHz 4x4 MIMO and 2.4 GHz 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
Maximum data rates of 4.8 Gbps in the 5 GHz band and 575 Mbps in the 2.4 GHz band

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: AP-584 models: 5.52 kg
AP-585 models: 5.24 kg
AP-587 models: 4.51 kg
AP-584 models: 12.17 lbs
AP-585 models: 11.55 lbs
AP-587 models: 9.94 lbs

Dimensions: AP-584 models: 24.4 x 32.4 x 31.2 cm (H x W x D)
AP-585 models: 32 x 32.4 x 31.3 cm (H x W x D)
AP-587 models: 17.4 x 30.2 x 30 cm (H x W x D)
Not including mounting bracket
AP-584 models: 9.6 x 12.6 x 12.3 in (H x W x D)
AP-585 models: 12.7 x 12.6 x 12.3 in (H x W x D)
AP-587 models: 6.9 x 11.9 x 11.8 in (H x W x D)
Not including mounting bracket

• Remote Wi-Fi 6E APs ideal for mission-critical remote work and small branches provide flexible coverage across any two bands (2.4 GHz, 5 GHz, and 6 GHz) for up to 3.6 Gbps combined peak data rate.
• Stay connected using backup or primary cellular connectivity with optional CAT 12 module that includes antennas and a high-speed interface for LTE connectivity.
• Convenient wired connectivity with 2.5 Gbps uplink/downlink Ethernet port and multiple 1 Gbps Ethernet ports.
• Zero Touch Provisioning provides ease of implementation in branch offices and remote sites, without on-site technical expertise.
• Managed through cloud-native HPE Aruba Networking Central to extend the WAN to home offices, small offices, and even temporary locations.

Certifications: Wi-Fi Alliance (WFA): Wi-Fi CERTIFIED a, b, g, n, ac; Wi-Fi CERTIFIED 6E (ax, 6GHz); WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE); WMM, WMM-PS, Wi-Fi Agile Multiband; Bluetooth SIG; Ethernet Alliance (PoE, PSE device, Class 3)

Input voltage: 48V/5W DC

Regulatory: FCC/ISED; CE Marked; RED Directive 2014/53/EU; EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU; UL/IEC/EN 60950; IEC/EN 62368-1; EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: Integrated omni-directional antennas for 2x2 MIMO with peak antenna gain of 5.5d Bi in 2.4 GHz, 5.5 dBi in 5 GHz and 5.5 dBi in 6 GHz. Built-in antennas are optimized for horizontal desk-mounted orientation of the AP.

Connectivity, standard: Wi-Fi 6E bands: 2.4 GHz, 5 GHz, 6 GHz plus an add-on cellular module for primary or backup connectivity.

Ports: Uplink (E0): Ethernet wired network port (RJ-45); Up-/downlink (E1): Ethernet wired network port (RJ-45); Downlink (E1-E3): Ethernet wired network ports (RJ-45); DC power interface; USB 2.0 host interface (Type A connector); Cellular radio module interface (accessible after removing the back cover); Serial console interface (proprietary, micro-B USB physical jack); Kensington security slot.

Mounting: The AP is intended to be desk mounted; the integrated antennas are optimized for that. See the ordering guide.

Power consumption: Maximum (worst-case) power consumption: 40W; Maximum (worst-case) power consumption in idle mode: 4.9W.

Radio coverage: Indoor, tri-radio, 2.4GHz, 5GHz and 6GHz (dual concurrent) 802.11ax 2x2 MIMO.

Warranty: Limited lifetime hardware warranty.

• Flagship Wi-Fi 6E access points provide tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate.
• 4x4 MIMO radios to deliver peak performance and increased capacity using multi-user (MU-MIMO) and orthogonal frequency-division multiple access (OFDMA) (uplink and downlink for both).
• Patented ultra tri-band (UTB) filtering enhances the use of 5 GHz and 6 GHz bands.
• High availability with dual 5 Gbps wired ports for redundant Ethernet and power.
• Built-in GPS receivers and intelligent software enable APs to self-locate and act as reference points for more accurate indoor location measurements.
• Internet of Things (IoT) ready with support for Bluetooth Low Energy (BLE) and Zigbee.

Certifications: UL2043 plenum rating
Wi-Fi Alliance (WFA):
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6E (ax, 6GHz)
WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, W-Fi Agile Multiband
Passpoint (release 2)
Bluetooth SIG
Ethernet Alliance (PoE, PD device, class 6)

Regulatory: The Wi-Fi 6E APs allow countries to take advantage of Wi-Fi 6E once it is approved in country via automated notification and easy deployment of 6 GHz regulatory rules.

For country-specific regulatory information and approvals, please see your HPE Networking representative.

Wi-Fi antenna: AP-654 supports external antennas.
AP-655 has internal antennas.

Connectivity, standard: Wi-Fi 6E (IEEE 802.11ax)

Mounting: A mounting bracket has been preinstalled on the back of the access point. This bracket is used to secure the access point to any of the mount kits (sold separately). For use with optional mounting kit, see the ordering guide.

Radio coverage: Indoor, tri-radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11ax 4x4 MIMO

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 1800g (3.97lb)

Dimensions: 260mm x 260mm x 56mm (10.24in x 10.24in x 2.2in)

• Cost-effective Wi-Fi 6 access points provide up to 1.49 Gbps maximum combined data rate.
• Supports Wi-Fi 6 (802.11ax) features including OFDMA for enhanced multi-user efficiency and WPA and Enhanced Open for greater security.
• Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
• Flexible management with AI-powered HPE Aruba Networking Central.
• Available as optional eco-friendly 10-packs.

Certifications: Ethernet Alliance (POE, PD device, Class 3)
Wi-Fi Alliance (WFA:
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6
WPA, WPA2 and WPA3- Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Agile Multiband

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1

Wi-Fi antenna: AP-503: Integrated down tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 1.7 dBi in 2.4 GHz and 4.8 dBi in 5 GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports:
E0: Ethernet wired network port (RJ-45)
USB 2.0 host interface (Type A connector)
Serial console interface (proprietary, micro-B USB physical jack)

Mounting: Optional mounting kits available, see the ordering guide.

Radio coverage: AP type: Indoor, dual-radio, 2.4 GHz and 5 GHz (dual concurrent) 802.11ax 2x2 MIMO

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 255g (0.5 lb)

Dimensions: 3.5 x 14.5 x 14.5 cm (1.38 x 5.7 x 5.7 cm)

• Cost-effective Wi-Fi 6 remote access points that provide up to 1.49 Gbps maximum combined data rate in a desktop form factor ideal for teleworker or small branch environments.
• Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
• Wired and wireless connections that include encryption and use authentication to protect the remote network.
• Optional USB LTE modem that supports high speed LTE Cat 12 connectivity for cellular backhaul.
• Zero Touch Provisioning that provides ease of implementation in branch offices and remote sites, without on-site technical expertise.
• Managed through cloud-native HPE Aruba Networking Central to extend the WAN to home offices, small offices, and even temporary locations.

Certifications: Wi-Fi Alliance (WFA)
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6
WPA, WPA2 and WPA3 - Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Agile Multiband

Input voltage: 12V/18W DC

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 60950
IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-503R: Integrated omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.9dBi in 2.4GHz and 5.1dBi in 5GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports:
E0: Ethernet wired network port (RJ-45);
E1-E2: Ethernet wired network ports (RJ-45)
USB-C: 5Vdc (nominal, +/- 5%); USB 2.0 host interface (Type A connector)
Serial console interface (proprietary, micro-B USB physical jack)
Kensington security slot.

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption: 15.4W
Maximum (worst-case) power consumption in idle mode: 4.0W

Radio coverage: AP type: Indoor, dual-radio, 2.4GHz and 5GHz (dual concurrent) 802.11ax 2x2 MIMO
2.4GHz radio: Two spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate with 2SS HE40 802.11ax client devices (287Mbps for HE20)
5GHz radio: Two spatial stream Single User (SU) MIMO for up to 1.2Gbps wireless data rate with 2SS HE80 802.11ax client devices

Warranty: Limited lifetime warranty.

• Wi-Fi 6 access points (APs) provide up to 2.97 Gbps combined aggregate data rate.
• Dual radio AP supporting 5 GHz and 2.4 GHz bands (4x4 MIMO).
• Protects network security with stronger encryption and authentication, secure credentials/keys storage, and user and IoT access policy enforcement firewalls (PEF).
• IoT-ready with support for1 Bluetooth 5 and Zigbee and two 5 Gbps ports for fast wired connectivity.
• Deploy models with internal antennas or connectorized models that support external antennas to meet range of environments.

Certifications: UL2043 plenum rating
Wi-Fi Alliance:
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6 (ax)
WPA, WPA2 and WPA3
Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, W-Fi Agile Multiband
Wi-Fi CERTIFIED Location
Bluetooth SIG

Input voltage: IEEE 802.3bt (class 5) or 802.3at PoE, or direct DC power (via optional power supply)

Wi-Fi antenna:
AP-534: Four (female) RP-SMA connectors for external dual band antennas (A0 through A3, corresponding with radio chains 0 through 3). Worst-case internal loss between radio interface and external antenna connectors : 0.8 dB in 2.4 GHz and 1.3 dB in 5 GHz

AP-535: Four integrated dual-band down tilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 3.5 dB in 2.4 GHz and 5.4 dB in 5 GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The down tilt angle for maximum gain is roughly 30 degrees.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports: (2) HPE Smart Rate RJ-45 port (maximum negotiated speed 5 Gbps)

Mounting: Pre-installed mounting bracket, for use with optional mounting kit, see the ordering guide.

Power consumption: POE powered (802.3bt or dual 802.3at): 30W POE powered (802.3at, IPM enabled): 25W DC powered: 29W; maximum (worst case)

Radio coverage: Dual-radio 4x4 MIMO IEEE 802.11ax AP with up-and downlink OFDMA and Multi-User MIMO (MU-MIMO). Maximum data rates of 2.4 Gbps in the 5 GHz band and 1,150 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 3.55 Gbps).

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 1.0 kg (2.2 lb)

Dimensions: 57 x 240 x 240 mm (AP-534), 80mm x 270 x 270 mm (AP-535) (2.2 x 9.4 x 9.4 in (AP-534), 2.8 x 9.1 x 8.7 in (AP-535))

• Entry-level outdoor Wi-Fi 6 (802.11ax) access points that provide up to 1.49 Gbps maximum aggregate data rate and are ideal for outdoor and warehouse environments.
• Purpose-built to survive in the harshest outdoor environments and extreme temperatures (-40?C to +65?C).
• Internet of Things (IoT)-ready with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee.
• Small form factor for flexible deployment.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls (PEF) that automatically enforces consistent policies across all networks, keeping users and devices secure.

Certifications: CB Scheme Safety, cTUVus
UL2043 plenum rating
Wi-Fi Alliance certified 802.11a/b/g/n/
Wi-Fi Alliance certified Wi-Fi 6 (802.11ax)
Wi-Fi CERTIFIED ac (with wave 2 features)
Wi-Fi CERTIFIED Location

Regulatory:
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN/UL 62368-1
EN 60601-1-1, EN60601-1-2
Railway Certs:
EN 50155:2017-Railway Applications
EN 50121-1:2017-Railway EMC
EN 50121-3-2-Railway EMC
EN 50121-4:2016-Railway Immunity
IEC 61373 ed2:2008-Railway Shock and Vibration

Wi-Fi antenna:
AP-565 models: Built-in omni-directional antennas.
AP-567 models: Built-in 90°H x 90°V directional antennas.

5 GHz:
Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with individual 2SS HE80 802.11ax client devices, or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously

2.4 GHz:
Two spatial stream Single User (SU) MIMO for up to 574 Mbps (287 Mbps) wireless data rate with individual 2SS HE40 (HE20) 802.11ax client devices or with two 1SS HE40 (HE20) 802.11ax MU-MIMO capable client devices simultaneously

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)
Bluetooth 5 and 802.15.4 radio
2.4 GHz–Bluetooth 5: up to 8 dBm transmit power and -95 dBm receive sensitivity
Zigbee: up to 8 dBm transmit power and -97 dBm receive sensitivity
Up to 4 dBm transmit power (class 2) and -91 dBm receive sensitivity

Ports: E0: 10/100/1000BASE-T (RJ-45)

Mounting: For use with optional mounting kit, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption: 15.6W
Maximum (worst case) power consumption in idle mode: 4.2W
Maximum (worst case) power consumption in deep-sleep mode: 1.7
Power sources sold separately

Radio coverage: AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 2x2 MIMO and 2.4 GHz 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 1.09 kg, max, depending on model (2.4 lb, max, depending on model)

Dimensions: 11 x 16.5 x 16.5 cm (4.3 x 6.5 x 6.5 in)

• High-performance Wi-Fi 6 (802.11ax) connectivity for harsh, weather-protected environments with maximum aggregate data rate of 3 Gbps (HE80/HE40).
• Purpose built to survive in harsh outdoor environments and extreme temperatures (-40?C to +65?C).
• Internet of Things (IoT)-ready with a built-in1 Bluetooth 5 and 802.15.4 radio that supports Zigbee.
• Connectorized APs that support external antennas and provide flexible deployment with support for both indoor and outdoor mounting brackets.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls (PEF) automatically enforces consistent policies across networks, keeping users and devices secure.

Certifications: CB Scheme Safety, cTUVus
UL2043 plenum rating
Wi-Fi Alliance certified 802.11a/b/g/n/
Wi-Fi CERTIFIED 6 (802.11ax)
Wi-Fi CERTIFIED ac (with Wave 2 features)
Passpoint (Release 2) with HPE Aruba Networking Operating System and InstantOS
Wi-Fi CERTIFIED Location

Regulatory:
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN/UL 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: 5 GHz: Four RP-SMA connectors for external antenna operation
2.4 GHz: Two RP-SMA connectors for external antenna operation

Ports: E0: HPE Smart Rate port (RJ-45)
E1: 100/1000BASE-T (RJ-45)
USB-C console interface

Power consumption: Maximum (worst-case) power consumption
PoE powered (dual ports): 32.0W
PoE powered (single port, full function): 26.1W
Maximum (worst-case) power consumption in idle mode: 14.0W (single PoE) or 16.0W (dual PoE)
Maximum (worst-case) power consumption in deep-sleep mode: 2.9W (single PoE) or 3.9W (dual PoE)
The AP supports Power over Ethernet (PoE) on port E0 and/or E1

Radio coverage: AP type: Indoor, dual radio, 5GHz 802.11ax 4x4 MIMO and 2.4GHz 802.11ax 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)

Warranty: Limited lifetime warranty

Weight: 1.5 kg (3.3 lbs)

Dimensions: 75 x 220 x 220 mm (H x W x D) (2.5 x 8.5 x 8.5 in (H x W x D))

• Wi-Fi 6 AP that provides up to 2.69 Gbps maximum combined data rate.
• Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
• IoT-ready with1 Bluetooth 5 and Zigbee support and fast wired connections with 2.5 Gbps Ethernet and 1 Gbps Ethernet ports.
• Client and RF optimization to match clients with one of the best available AP and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
• Offered in optional eco-friendly 10-packs.

Certifications:
UL2043 plenum rating
Bluetooth SIG
Wi-Fi Alliance:
Wi-Fi CERTIFIED a, b, g, n, ac, ax
WPA, WPA2 and WPA3, Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, W-Fi Agile Multiband
Wi-Fi CERTIFIED Location

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2
Railway Certs (AP-515 Only):
EN 50155:2017-Railway Applications
EN 50121-1:2017-Railway EMC
EN 50121-3-2-Railway EMC
EN 50121-4:2016-Railway Immunity
IEC 61373 ed2:2008-Railway Shock and Vibration

Wi-Fi antenna: AP-514: Four (female) RP-SMA connectors for external dual band antennas (A0 through A3, corresponding with radio chains 0 through 3 for 5 GHz; 2.4 GHz radio uses A0/A1 and chains 0/1 only).
AP-515: Four integrated dual-band downtilt omnidirectional antennas for 4x4 MIMO (2x2 MIMO for 2.4 GHz) with peak antenna gain of 4.2 dBi in 2.4 GHz and 7.5 dBi in 5 GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports:
E0: HPE Smart Rate port (RJ-45, maximum negotiated speed 2.5 Gbps)
E1: 10/100/1000BASE-T Ethernet network interface (RJ-45)
USB 2.0 host interface (Type A connector)
Serial console interface (proprietary, micro-B USB physical jack)

Mounting: Pre-installed mounting bracket, for use with optional mounting kit, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption:
DC powered: 16.0W
PoE powered (802.3af, IPM enabled): 13.5W
PoE powered (802.3at/bt): 20.8W

Maximum (worst-case) power consumption in idle mode: 12.6W (PoE) or 9.7W (DC)
Maximum (worst-case) power consumption in deep-sleep mode: 5.9W (PoE) or 1.5W (DC)

Radio coverage: AP type: Indoor, dual radio, 5 GHz 802.11ax 4x4 MIMO and 2.4 GHz 802.11ax 2x2 MIMO

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 810 g (28.5 oz)

Dimensions: 46 x 200 x 200 mm (1.8 x 7.9 x 7.9 in)

• Entry level Wi-Fi 6 access points provide up to 1.49 Gbps maximum combined data rate.
• Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
• IoT-ready with built-in1 Bluetooth 5 and Zigbee support.
• Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
• Built-in technology that resolves sticky client issues and improves performance of mobile Wi-Fi clients.
• Available in optional eco-friendly 10-packs.

Certifications: UL2043 plenum rating
Wi-Fi Alliance:
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6 (ax)
WPA, WPA2 and WPA3-Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, W-Fi Agile Multiband
Wi-Fi CERTIFIED Location™
Bluetooth SIG
Ethernet Alliance (PoE, PD device, Class 4)

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-504 models: Two RP-SMA connectors for external dual band antennas.
AP-505 models: Two integrated dual-band downtilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.9 dBi in 2.4 GHz and 5.7 dBi in 5 GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports:
E0: Ethernet wired network port (RJ-45)
USB 2.0 host interface (type A connector)
Serial console interface (proprietary, micro-B USB physical jack)
Kensington security slot.

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption (without/with a USB device attached):
PoE powered (802.3at): 11.0W / 16.5W
PoE powered (802.3af): 11.0W / 13.5W
This assumes that up to 5W is supplied to the attached USB device
Maximum (worst-case) power consumption in idle mode: 4.3W (DC) or 6.2W (PoE)
Maximum (worst-case) power consumption in deep-sleep mode: 1.7W (DC) or 3.7W (PoE)

Radio coverage: AP type: Indoor, dual radio, 5 GHz and 2.4 GHz 802.11ax 2x2 MIMO
5 GHz radio: Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with 2SS HE80 802.11ax client devices.
2.4 GHz radio: Two spatial stream Single User (SU) MIMO for up to 574 Mbps (287 Mbps) wireless data rate with 2SS HE40 (HE20) 802.11ax client devices.

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 500 g (1.1 lb)

Dimensions: 37 x 160 x 161 mm (1.5 x 6.3 x 6.3 in)

• High-performance Wi-Fi 6 access points (APs)provide up to 5.37 Gbps combined aggregate data rate
• Optional tri-radio mode with two 5 GHz and one 2.4 GHz radio (4x4 MIMO).
• Protects with encryption and authentication, secure credentials/keys storage, and user and IoT access policy enforcement firewalls (PEF).
• IoT-ready with support for1 Bluetooth 5 and Zigbee.
• Two 5 Gbps ports for fast wired connectivity.

Certifications: UL2043 plenum rating
Bluetooth SIG
WI-FI Alliance:
Wi-Fi CERTIFIED a, b, g, n, ac, ax
WPA, WPA2 and WPA3
Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, W-Fi Agile Multiband
Wi-Fi CERTIFIED Location

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2
For more country-specific regulatory information and approvals, contact your HPE representative

Wi-Fi antenna: Integrated downtilt omni-directional antennas for 4x4 MIMO in 2.4 GHz with peak antenna gain of 4.3 dBi, and 8x8 MIMO in 5 GHz with peak antenna gain of 5.8 dBi in 5 GHz.
In tri-radio mode, the peak gain of the antennas for each of the 4x4 5 GHz radios is 5.5 dBi (radio 0L, lower half of 5GHz) and 5.6 dBi (radio 0U, upper half of 5 GHz).
Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Ports: E0, E1: HPE Smart Rate port (RJ-45, maximum negotiated speed 5 Gbps)
Serial console interface (proprietary, micro-B USB physical jack)
USB 2.0 host interface (Type A connector)

Mounting: Pre-installed mounting bracket, for use with optional mounting kit, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption (dual-radio operation):
DC powered: 32.6W
PoE powered (802.3bt or dual 802.3at): 38.2W
PoE powered (802.3at, IPM disabled): 25.1W
All numbers above are without an external USB device connected. When sourcing the full 5W power budget to such a device, the incremental (worst-case) power consumption for the AP is up to 6.0W (PoE powered) or 5.4W (DC powered).
Maximum (worst-case) power consumption in idle mode (dual-radio operation): 15.0W (PoE) or 15.1W (DC)
Maximum (worst-case) power consumption in deep-sleep mode: 3.8W(PoE) or 3.6W (DC)

Radio coverage: AP type: Indoor, dual/tri-radio, 5 GHz and 2.4 GHz 802.11ax 4x4 MIMO
5 GHz radio (dual-radio operation): Eight spatial stream HE80 (or 4SS HE160) MIMO for up to 4.8 Gbps wireless data rate
5 GHz radio (tri-radio operation): Four spatial stream HE80 (or 2SS HE160) MIMO for up to 2.4 Gbps wireless data rate
2.4 GHz radio: Four spatial stream HE40 (HE20) MIMO for up to 1,147 Mbps (574Mbps)

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: 1.57 kg (3.46 lb)

Dimensions: 58 x 260 x 260 mm (2.3 x 10.2 x 10.2 in)

• Outdoor Wi-Fi 6 access points provide up to 2.69 Gbps maximum aggregate data rate.
• Purpose-built to survive in the harshest outdoor environments and extreme temperatures (-40?C to +65?C).
• IoT-ready with a built-in Bluetooth 51 and 802.15.4 radio that supports Zigbee.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls automatically enforces consistent policies across networks, keeping users and devices secure.

Certifications: CB Scheme Safety, cTUVus
UL2043 plenum rating
Wi-Fi Alliance certified 802.11a/b/g/n/
Wi-Fi CERTIFIED 6 (802.11ax)
Wi-Fi CERTIFIED ac (with Wave 2 features)
Passpoint (Release 2) with HPE Aruba Networking Operating System and Instant
Wi-Fi CERTIFIED Location

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN/UL 62368-1
EN 60601-1-1, EN60601-1-2
Railway Certs:
EN 50155:2017-Railway Applications
EN 50121-1:2017-Railway EMC
EN 50121-3-2-Railway EMC
EN 50121-4:2016-Railway Immunity
IEC 61373 ed2:2008-Railway Shock and Vibration

Wi-Fi antenna: AP-574 models: Four Nf connectors for external antenna (5 GHz operation), and two Nf connectors for external antenna (2.4 GHz operation)
AP-575 models: Built-in omni-directional antennas: 5 GHz (5 dBi), 2.4 GHz (3.4 dBi)
AP-577 models: Built-in 90°H x 90°V directional antennas: 5 GHz (5.6 dBi), 2.4 GHz (6.8 dBi)

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption:
PoE powered (dual ports): 32.0W
PoE powered (single port, full function): 26.1W
Maximum (worst-case) power consumption in idle mode: 14.0W (single PoE) or 16.0W (dual PoE)
Maximum (worst-case) power consumption in deep-sleep mode: 2.9W (single PoE) or 3.9W (dual PoE)

Radio coverage: AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 4x4 MIMO and 2.4 GHz 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1) 5 GHz

Warranty: Limited lifetime warranty. See the warranty duration.

Weight:
AP-574 models: 2.4 kg
AP-575 models: 2.4 kg
AP-577 models: 2.1 kg
AP-574 models: 5.3 lbs
AP-575 models: 5.3 lbs
AP-577 models: 4.6 lbs

Dimensions:
AP-574 models: 19 x 23 x 24 cm (H x W x D)
AP-575 models: 27 x 23 x 24 cm (H x W x D)
AP-577 models: 13 x 23 x 22 cm (H x W x D)
Not including mounting bracket
AP-574 models: 7.5 x 9.0 x 9.4 in (H x W x D)
AP-575 models: 10.6 x 9.0 x 9.4 in (H x W x D)
AP-577 models: 5.1 x 9.0 x 8.7 in (H x W x D)
Not including mounting bracket

• High performance outdoor Wi-Fi 6E access points ideal for outdoor and environmentally challenging locations
• Delivers up to 3.9 Gbps maximum aggregate data rates with a tri-radio 2x2:2 MIMO
• 160 MHz channels in 6 GHz support low-latency, bandwidth-hungry applications like high-definition video and AR/VR applications
• High-power Bluetooth1 and Zigbee radios to meet Industrial IoT requirements
• Flexible and fast-wired connectivity with 2.5 GbE port and 1 GbE SFP port. The series includes models with internal antennas and new connectorized model that supports external antennas
• Self-locating with embedded GPS receiver and will operates as Standard Power (SP) device

Certifications:
Wi-Fi Alliance;
Bluetooth SIG;
Ethernet Alliance (E0, PoE PD Device Class 6)

Input voltage: IEEE 802.3bt PoE, or direct DC power (through optional power supply)

Regulatory:
FCC/ISED;
CE Marked;
RED Directive 2014/53/EU;
EMC Directive 2014/30/EU;
Low Voltage Directive 2014/35/EU;
IEC/EN 62368-1;
EN 60601-1-1, EN60601-1-2;

For more country-specific regulatory information and approvals, contact your HPE Aruba Networking representative.

Wi-Fi antenna:
AP-674: External antenna model (6 connectors total)
Two (Nf) connectors for 2.4 GHz + 5 GHz dual-band external antennas
Two (Nf) connectors for 6GHz external antennas
One (Nf) connector for BLE/IoT radio (includes a 5d Bi omni-directional external antenna)
One (Nf) connector for the included (TNCf) GPS antenna (includes mounting bracket and cable)

AP-675: Internal antenna model
Built-in Omnidirectional Antennas
2.4 GHz Antennas 3.8 dBi
5 GHz Antennas 5.7 dBi
6 GHz Antennas 5.9 dBi
BLE/Zigbee: Integrated omnidirectional antenna with peak gain of 4.5 dBi

AP-677: Internal antenna model
Built-in Directional Antennas
2.4 GHz Antennas 6.9 dBi
5 GHz Antennas 6.5 dBi
6 GHz Antennas 6.9 dBi
BLE/Zigbee: Integrated omnidirectional antenna with peak gain of 4.5 dBi

AP-679: Internal antenna model
Built-in Directional Antennas
2.4 GHz Antennas 6.1 dBi
5 GHz Antennas
Wide 7.1 dBi
Narrow 10.1 dBi
6 GHz Antennas
Wide 7.7 dBi
Narrow 11.2 dBi
BLE/Zigbee: Integrated omnidirectional antenna with peak gain of 6.6 dBi

Connectivity, standard: Wi-Fi 6E (IEEE 802.11ax)

Ports: (1) 10/100/1000BASE-T RJ-45 port, auto-sensing link speed and MDI/MDX
(1) SFP Fiber port

Mounting: A mounting bracket has been preinstalled on the back of the access point. This bracket is used to secure the access point to any of the mount kits (sold separately). See the ordering guide.

Power consumption: Up to 45.5W maximum

Radio coverage:
AP type: Outdoor, tri radio, 2.4GHz, 5GHz and 6GHz (concurrent) 802.11ax 2x2 MIMO;
2.4 GHz radio: Two spatial stream Single User (SU) MIMO for up to 574 Mbps wireless data rate with 2SS HE40 802.11ax client devices;
5 GHz radio: Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with 2SS HE80 802.11ax client devices;
6 GHz radio: Two spatial stream Single User (SU) MIMO for up to 2.4 Gbps wireless data rate with 2SS HE160 802.11ax client devices;
Up to 512 associated client devices per radio, and up to 16 BSSIDs per radio (limited to 8 for the 6GHz radio)

Warranty: Limited lifetime warranty.

• Fast, secure, and cost-effective Wi Fi 7 access points for high-density campus deployments.
• Comprehensive tri?band coverage across 2.4 GHz, 5 GHz, and 6 GHz delivers up to 4.7 Gbps maximum aggregate data rate.
• Flexible integrated IoT radio can be configured for Bluetooth or 802.15.4/Zigbee operation.
• AI-powered orchestration and management with HPE Aruba Networking Central.
• Fast 2.5 Gbps Ethernet wired connectivity and is conveniently powered by PoE (IEEE 802.3af/at).
• Fixed indoor access points with integrated antennas are part of the Low Power Indoor (LPI) device class,

Certifications: Bluetooth SIG; Ethernet Alliance (PoE, PD device, Class 4)
Wi?Fi Alliance (WFA):
- Wi?Fi CERTIFIED a, b, g, n, ac, 6, 7
- WPA2 and WPA3
- Enhanced Open (OWE)
- WMM, W?Fi Agile Multiband

Input voltage: PoE?PD: 48Vdc (nominal) 802.3af/at PoE (Class 3 or higher);

Regulatory: FCC/ISED; CE Marked; RED Directive 2014/53/EU; UL/IEC/EN 62368?1

Wi-Fi antenna: Integrated down-tilt omni?directional antennas for 2x2 MIMO with peak antenna gain of 5.1 dBi in 2.4 GHz, 5.4 dBi in 5 GHz, and 5.4 dBi in 6 GHz. Built?in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.

Connectivity, standard: Wi-Fi 7 (IEEE 802.11be)

Ports:
E0: Ethernet wired network port (RJ?45);
U0: USB 2.0 host interface (Type A connector);
Kensington security slot;
Serial console interface (proprietary, micro?B USB physical jack);
Reset button: Factory reset, LED mode control (normal/off);
Visual indicators (four multi?color LEDs) for System (1x) and Radio (3x) status

Mounting: A mounting bracket has been preinstalled on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately). Optional mounting kits available, see the 720 Series ordering guide.

Power consumption: Maximum (worst case) power consumption (without/with USB devices attached): 17.1W/22.8W.
Notes:
This assumes that up to 5W is supplied to the attached USB device.
Maximum (worst?case) power consumption in idle mode: 7.0W/12.5W (PoE).
Maximum (worst?case) power consumption in deep?sleep mode: 3.5W (PoE).

Radio coverage: AP type: Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz (concurrent) 802.11be 2x2 MIMO

Warranty: Limited lifetime warranty.

• High performance Wi-Fi 6E access point ideal for hospitality, branch, and teleworker deployments.
• Flexible coverage across any two bands (2.4 GHz, 5 GHz, and 6 GHz) for up to 3.6 Gbps combined peak data rate.
• Up to seven 160MHz channels in 6 GHz support low-latency, bandwidth-hungry applications such as high-definition video and AR/VR applications.
• Combines wireless and wired access in compact desktop or wall mount model that can be PoE powered.
• IoT-ready with support for1 Bluetooth 5 and Zigbee.

Certifications: Wi-Fi Alliance (WFA):
Wi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6
WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Agile Multiband
Wi-Fi CERTIFIED Location TM
Bluetooth SIG
Ethernet Alliance (PoE PD device, Class 6 and PoE PSE device, Class 4)

Input voltage: IEEE 802.3af/at/bt (class 3, 4, or 6) PoE, or direct 48V DC power (via optional power supply)

Regulatory: FCC/ISED; CE Marked; RED Directive 2014/53/EU; EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU; IEC/EN 62368-1; EN 60601-1-1, EN60601-1-2; UL2043

Wi-Fi antenna: AP-605H: Integrated omni-directional antennas for 2x2 MIMO with peak antenna gain of 5.1 dBi in 2.4 GHz, 5.1 dBi in 5 GHz and 5.4 dBi in 6 GHz.

Heat dissipation: Up to 65.2 BTU/hr (worst case, AP unit only, with full USB and PSE load)

Connectivity, standard: Wi-Fi 6E (IEEE 802.11ax)

Ports: 1x Ethernet port (RJ45), auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX. 2.5 Gbps speed complies with NBASE-T and 802.3bz specifications 4x Ethernet 10/100/1000BASE-T ports (RJ45), auto-sensing link speed and MDI/MDX 1x USB 2.0 host interface (Type A connector).

Mounting: Using one of the (separate orderable) mount kits, the access point can be attached to a single or dual gang wall box, directly to a wall, or desk mounted. See the ordering guide.

Power consumption: Up to 50W (worst case, AP with full USB and PSE load)

Radio coverage: AP type: Indoor, tri-band, 2.4 GHz, 5 GHz and 6 GHz (dual concurrent) 802.11ax 2x2 MIMO

Warranty: Limited lifetime warranty.

• Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 access points that provide up to 1.49 Gbps maximum aggregate data rate.
• Purpose built for hazardous locations and to survive in one of the harshest outdoor environments and extreme temperatures (-40?C to +65?C).
• Internet of Things (IoT)-ready with a built-in1 Bluetooth 5 and 802.15.4 radio that supports Zigbee.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls (PEF) that automatically enforces consistent policies across all networks, keeping users and devices secure.

Certifications: CB Scheme Safety, cTUVus
UL2043 plenum rating
Wi-Fi Alliance certified 802.11a/b/g/n/
Wi-Fi Alliance certified Wi-Fi 6 (802.11ax)
Wi-Fi CERTIFIED ac (with wave 2 features)
Wi-Fi CERTIFIED Location
Class 1 Division 2 certified
ATEX Zone 2 certified

Regulatory: FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN/UL 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-565EX: Built-in Omni Directional Antennas
AP-567EX: Built-in 90°H x 90°V Directional Antennas

5GHz:
Two spatial stream Single User (SU) MIMO for up to 1.2 Gbps wireless data rate with individual 2SS HE80 802.11ax client devices, or with two 1SS HE80 802.11ax MU-MIMO capable client devices simultaneously.

2.4GHz:
Two spatial stream Single User (SU) MIMO for up to 574 Mbps (287 Mbps) wireless data rate with individual 2SS HE40 (HE20) 802.11ax client devices or with two 1SS HE40 (HE20) 802.11ax MU-MIMO capable client devices simultaneously.

Connectivity, standard: Wi-Fi 6 (802.11ax)
Bluetooth 5 and 802.15.4 radio
2.4 GHz
Bluetooth 5: up to 8 dBm transmit power and -95 dBm receive sensitivity
Zigbee: up to 8 dBm transmit power and -97 dBm receive sensitivity
Up to 4 dBm transmit power (class 2) and -91 dBm receive sensitivity
Visual indicator (multi-color LED): For system and radio status

Ports:
Reset button: Factory reset (during device power up)
USB-C console interface
E0: 10/100/1000BASE-T (RJ-45)
Auto-sensing link speed and MDI/MDX
PoE-PD: 48 VDC (nominal) 802.3at/bt (Class 3 or higher)
802.3az Energy Efficient Ethernet (EEE)

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: Maximum (worst-case) power consumption: 15.6W
Maximum (worst case) power consumption in idle mode: 4.2W
Maximum (worst case) power consumption in deep-sleep mode: 1.7
Power sources sold separately

Radio coverage: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 2x2 MIMO and 2.4 GHz 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
Up to 256 associated client devices per radio
Up to 16 BSSIDs per radio

Warranty: Limited lifetime warranty.

• Purpose-built to survive in one of the harshest outdoor environments with Hazardous Location Class 1 Division 2, and ATEX Zone 2, and IP66 rating for hazardous locations.
• Wi-Fi 6 capabilities to deliver multi-gigabit performance and speed with a maximum aggregate data rate of 2.97 Gbps.
• The AP supports for 5 Gbps multi-gigabit Ethernet ports and 802.3bt Class 6 power or AC power included, no need for add-on AC power adapters.
• Features high power Bluetooth1 and 802.15.4/Zigbee support for Industrial IoT.
• Seamless connectivity with RF automation (AirMatch), client optimization (ClientMatch), and AIOps (AI Insights) for built-in configuration recommendations.

Certifications:
Wi-Fi Alliance
Bluetooth SIG
Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3)
Class 1 Div 2
ATEX Zone 2
IECEx

Input voltage: AC power interface: 110-240V (requires AP-AC-MLX power connector BT)

Regulatory:
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC 60950-22
UL/IEC/EN 62368-1
IEC/EN60601-1-2
EN 50155
EN IEC 60079-0
EN IEC 60079-7
IEC 60079-0
IEC 60079-7
CSA C22.2 No.213-17
UL 121201
UL 50E

Wi-Fi antenna: AP-585EX: Four integrated dual-band omni-directional antennas for 4x4 MIMO with peak antenna gain of 4.4 dBi in 2.4 GHz and 5.8 dBi in 5 GHz.
AP-587EX: Four integrated 90°H x 90°V dual-band directional antennas for 4x4 MIMO with peak antenna gain of 5.8 dBi in 2.4 GHz and 6.6 dBi in 5 GHz.

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Mounting: Optional mounting kits available, see the ordering guide.

Power consumption: The AP supports direct AC power and Power over Ethernet (802.3bt PoE; on port E0 only).
When both AC and PoE power sources are available, AC power takes priority over PoE.
Power sources are sold separately.

Radio coverage: AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz and 2.4 GHz 802.11ax 4x4 MIMO.
5GHz radio: Four spatial stream Single User (SU) MIMO for up to 2.4Gbps wireless data rate with individual 4SS HE80 (or 2SS HE160) 802.11ax client devices, or with four 1SS or two 2SS HE80 802.11ax MU-MIMO capable client devices simultaneously.
2.4GHz radio: Four spatial stream Single User (SU) MIMO for up to 1,150Mbps wireless data rate with individual 4SS HE40 802.11ax client devices or with two 2SS HE40 802.11ax MU-MIMO capable client devices simultaneously.

Warranty: Limited lifetime warranty. See the warranty duration.

Weight:
AP-585EX models: 5.24 kg
AP-587EX models: 4.51 kg
AP-585EX models: 11.5 lbs
AP-587EX models: 9.9 lbs

Dimensions:
AP-585EX models: 32 x 32.4 x 31.3 cm (H x W x D)
AP-587EX models: 17.4 x 30.2 x 30 cm (H x W x D)
Not including mounting bracket
AP-585EX models: 9.6 x 12.6 x 12.3 in (H x W x D)
AP-587EX models: 6.9 x 5.9 x 11.8 in (H x W x D)
Not including mounting bracket

• Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 access points provide up to 2.69 Gbps maximum aggregate data rate.
• Purpose built for hazardous locations and to survive in some of the harshest outdoor environments and extreme temperatures (-40?C to +65?C).
• Provides policy enforcement for wireless traffic through Dynamic Segmentation.
• IoT-ready with a built-in Bluetooth 51 and 802.15.4 radio that supports Zigbee.
• Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
• Dynamic Segmentation and policy enforcement firewalls automatically enforces consistent policies across networks, keeping users and devices secure.

Certifications: CB Scheme Safety, cTUVus
UL2043 plenum rating
Wi-Fi Alliance certified 802.11a/b/g/n/
Wi-Fi CERTIFIED 6 (802.11ax)
Wi-Fi CERTIFIED ac (with Wave 2 features)

Regulatory:
FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN/UL 62368-1
EN 60601-1-1, EN60601-1-2

Wi-Fi antenna: AP-575EX models: Built-in omni-directional antennas: 5 GHz (4.6 dBi), 2.4 GHz (4.0 dBi)
AP-577EX models: Built-in 90°H x 90°V directional antennas: 5 GHz (6.3 dBi), 2.4 GHz (6.4 dBi)

Connectivity, standard: Wi-Fi 6 (IEEE 802.11ax)

Mounting: Optional mounting kits. See the ordering guide.

Power consumption: Maximum (worst-case) power consumption:
PoE powered (dual ports): 32.0W
PoE powered (single port, full function): 26.1W
Maximum (worst-case) power consumption in idle mode: 14.0W (single PoE) or 16.0W (dual PoE)
Maximum (worst-case) power consumption in deep-sleep mode: 2.9W (single PoE) or 3.9W (dual PoE)

Radio coverage: AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 4x4 MIMO and 2.4 GHz 2x2 MIMO
Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)

Warranty: Limited lifetime warranty. See the warranty duration.

Weight: AP-575EX models: 2.4 kg
AP-577EX models: 2.1 kg
AP-575EX models: 5.3 lbs
AP-577EX models: 4.6 lbs

Dimensions: AP-575EX models: 27 x 23 x 24 cm (H x W x D)
AP-577EX models: 13 x 23 x 22 cm (H x W x D)
Not including mounting bracket
AP-575EX models: 10.6 x 9.0 x 9.4 in (H x W x D)
AP-577EX models: 5.1 x 9.0 x 8.7 in (H x W x D)
Not including mounting bracket

• Wi-Fi CERTIFIED 6 support for up to 75 user devices.
• Provide Wi-Fi for the outdoors.
• IP67 rated for outdoor use from -40°C to 60°C.
• The hardened external shell protects from rain, wind, and dust.
• Great at extending Wi-Fi to a patio, outdoor workspace, or curbside deliveries.
• Introducing new TEC Certified SKU (S3U62A) for India

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: PoE: 802.3at (class 4) DC power (12V)

Note: Power sources are sold separately unless you purchase the bundle SKU

Wi-Fi antenna:
Antennas: Dual omni-directional 2x2 MIMO
Antenna Gain: 3.2 dBi in 2.4GHz 5.4 dBi in 5GHz
Maximum transmit power:
5GHz band: +25 dBm (+22 dBm per chain, 3 dB MIMO gain)
2.4GHz band: +25 dBm (+22 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax

Ports:
1 GbE Base-T uplink port
LED status indicators
Reset button
Kensington security slot

Mounting: Wall-mount bracket

Power consumption: Max power consumption: 14.6W (PoE)

Radio coverage: Dual-radio 802.11ax
2x2 5GHz MIMO
2x2 2.4GHz MIMO

Warranty: Instant On 2-year warranty

• Wi-Fi CERTIFIED 6 support for up to 50 user devices.
• Designed to provide better speed and coverage for smaller spaces.
• PoE or DC powered to expand your network.
• Use with any other Instant On access points to create a Smart Mesh to extend your network without additional ethernet cables.
• Best when used in conference rooms, home offices, or low-density environments.

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: PoE: 802.3af (class 3) DC power (12V)

Note: Power sources are sold separately unless you purchase the bundle SKU

Wi-Fi antenna:
Antennas: Dual Omni-directional 2x2 MIMO
Antenna Gain:1.7 dBi in 2.4 GHz and 4.8 dBi in 5 GHz
Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax

Ports:
1 GbE Base-T uplink port
DC power connector
LED status indicators
Reset/LED control button
Kensington security slot

Mounting: Ceiling/Wall mount clip

Power consumption: 10.1W (PoE) or 10.9W (DC)

Radio coverage: Dual-radio 802.11ax/n
2x2 5 GHz/2.4 GHz MIMO

Warranty: Instant On 2-year warranty

• Wi-Fi CERTIFIED 6E support for up to 75 user devices.
• 2.5 Gigabit Ethernet uplink port that relieves bottlenecks brought by bandwidth-intense applications.
• 6 GHz band dedicated to Wi-Fi 6E-enabled devices with up to 2.4 Gbps wireless throughput.
• The modern minimal design blends the HPE Networking Instant On AP32 into any environment. Enable quiet mode to disable lights for less distraction.
• Keep your network protected with the HPE Networking Instant On Instant On mobile app or web portal, cloud-connected so you can manage or troubleshoot problems anywhere in the world.

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: PoE: 802.3at (class 4) DC power (12V)

Note: Power sources are sold separately unless you purchase the bundle SKU

Wi-Fi antenna:
Antennas: Dual omni-directional 2x2 MIMO
Antenna Gain: 2.8 dBi in 2.4 GHz 4.5 dBi in 5 GHz and 6 GHz
Maximum transmit power:
5 GHz and 6 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax

Ports:
1x 2.5 GbE Base-T uplink port
DC power connector
LED status indicators
Reset/LED control button
Kensington security slot

Mounting: Ceiling/Wall-mount clip

Power consumption: Max power consumption: 12.9W (PoE) 11.0W (DC)

Radio coverage: Dual-Radio, tri-band 802.11ax
2x2 6 GHz/5 GHz/2.4 GHz MIMO

Warranty: Instant On 2-year warranty

• Wi-Fi CERTIFIED 6 wireless access point, with 2.5 GbE uplink port
• 2.5 GbE uplink port provides up to 2x more bandwidth than 1 GbE ports without the need for new Cat5/6(a) cables to be installed.
• Four 1 GbE downlink ports that supply up to 2x 15W of PoE (802.3af).
• Up to 1.7 Gbps aggregate wireless throughput.

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: PoE: 802.3bt (class 6) Full functionality or 802.3at (class 4) limited functionality DC power (48V)
PoE In: 802.3at/802.3bt
POE Out: 2x 15W PoE (802.3af)

Note: Power sources are sold separately unless you purchase the bundle SKU

Wi-Fi antenna:
Antennas: Dual semi-directional 2x2 MIMO
Antenna Gain: 5.2 dBi in 2.4GHz and 5.4 dBi in 5 GHz
Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +20 dBm (+17 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax

Ports: 1x 2.5 GbE Base-T PoE Class 4/6 uplink
2x 1 GbE Base-T PoE Class 3 downlink
2x 1 GbE Base-T downlink
DC power connector
LED status indicators
Reset/LED control button
Kensington security slot

Mounting: Gang wall box-mount kit or Desk-mount kit

Power consumption: 51W (PoE) or 50W (DC)

Radio coverage: Dual-radio 802.11ax
2x2 5 GHz/2.4 GHz MIMO

Warranty: Instant On 2-year warranty

• Provides a high-performance Dual Radio 802.11ax AP with 4 spatial streams (4X4) for higher capacity and coverage
• This series features maximum data rates of 4.8 Gbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 5.3 Gbps)
• Includes 2.5 Gigabit Ethernet uplink port and 160 MHz channel bandwidth for increased wireless throughput
• Wi-Fi 6 certification supports all mandatory 802.11ax features that include MU-MIMO, OFDMA, TWT, and more
• Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access
• Instant On mobile app and/or cloud-based web portal allows for easy network management onsite or remotely

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: PoE: 802.3at (class 4) DC power (12V)

Wi-Fi antenna:
Antennas: Dual omni-directional 4x4 MU-MIMO
Antenna Gain: 3.7 dBi in 2.4GHz 4.5 dBi in 5 GHz
Maximum transmit power:
5 GHz band: +24 dBm (+18 dBm per chain, 6 dB MIMO gain)
2.4 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax, 4x4:4

Ports: 1x 2.5 GbE Base-T uplink port
DC power connector
Bluetooth Low Energy (BLE)
LED status indicators
Reset/LED control button
Kensington security slot

Mounting: Ceiling/Wall mount clip

Power consumption: Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC)

Radio coverage: Dual-radio 802.11ax
4x4 5 GHz MU-MIMO
2x2 2.4 GHz MU-MIMO

Warranty: Instant On 2-year warranty includes 24X7 phone support for the first 90 days and chat support for the entire warranty period.
Community support is available for the life of the product.

Weight: 1.18 kg (2.6 lb)

Dimensions: 5.1 x 20.3 cm (2 x 8 x 8 in)

• Wi-Fi 6 for high performance and efficiency
• Supports up to 75 associated clients
• Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access

Certifications: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltage: Power over Ethernet (PoE): 802.3af (class 3) DC power (12V)

Wi-Fi antenna:
Antennas: Down-tilt Dual Omni-directional 2x2 MIMO
Antenna Gain: 4.9 dBi in 2.4 GHz 5.7 dBi in. 5 GHz
Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +20 dBm (+17 dBm per chain, 3 dB MIMO gain)

Connectivity, standard: Ultra-fast 802.11ax

Ports:
1 GbE Base-T uplink port
DC power connector
Bluetooth Low Energy (BLE)
LED status indicators
Reset/LED control button
Kensington security slot

Mounting: Ceiling/Wall-mount clip

Power consumption: Max power consumption: 10.1W (PoE), 8.8W (DC)

Radio coverage: Dual-radio 802.11ax, 2x2 5 GHz/2.4 GHz MIMO

Warranty: Instant On 2-year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products.

Weight: 500 g (1.1 lb)

Dimensions: 37x 160 x 160 mm (1.5 x 6.3 x 6.3 in)

• 802.11ac support
• 4x4 MIMO, 3 spatial streams
• Flexible antenna port
• 802.11n Version 2.0 capabilities
• 4x4 MIMO with three spatial streams (3SS)
• Maximal Ratio Combining (MRC)
• 802.11n and 802.11a/g Beamforming
• 20- and 40-MHz channels
• PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
• Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11ac Wave 1 capabilities
• 4x4 MIMO with three spatial streams (3SS)
• Maximum Ratio Combining (MRC)
• 802.11ac Beamforming
• 20-, 40-, and 80-MHz channels
• PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
• Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• Data Rates Supported: 2.4 GHz - 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
• Interface
• WAN port 10/100/1000BASE T Ethernet, autosensing (RJ-45)
• LAN port 10/100/1000BASE T Ethernet, autosensing (RJ-45)
• Fiber SFP
• Cable modem: NA-DOCSIS3.0/Euro-DOCSIS3.0/Japan-DOCSIS3.0 (8x4, 16x8, or 24x8)
• Management console port (RJ-45)
• Four multicolor LEDs
• Reset button
• Uplink options
• 1572EAC Ethernet, Fiber SFP, Wireless Mesh
• 1572IC Ethernet, Fiber SFP, Wireless Mesh, Cable Modem
• 1572EC Ethernet, Fiber SFP, Wireless Mesh, Cable Modem
• Dimensions (L x W x D): 1572EAC / 1572EC 11.8 x 7.9 x 6.3 in. (30.0 x 20.1 x 16.0 cm)
• 1572IC 11.8 x 7.9 x 7.9 in. (30.0 x 20.1 x 20.1 cm)
• Weight
• 1572EAC/1572EC 13.5 lbs (6.1 kg)
• 1572IC 11.5 lbs (5.2 kg)
• Pole mounting Kit 1 (PMK1):2.2 lbs (1.0 kg)
• Pole mounting Kit 2 (PMK2):4.4 lbs (2.0 kg)
• Pole mounting Kit 3 (PMK3):6.1 lbs (2.8 kg)
• Cable strand mounting bracket 1 (SMK1): 0.3 lbs (0.2 kg)
• Cable strand mounting bracket 2 (SMK2): 0.7 lbs (0.3 kg)
• Cable strand mounting bracket 2 (SMK3): 1.2 lbs (0.5 kg)
• Warranty: 1 year limited Hardware warranty

• Aironet 1562I
• 802.11ac Wave 2 support
• 3x3 MU-MIMO, 3 spatial streams
• Internal antenna
• Aironet 1562E
• 802.11ac Wave 2 support
• 2x2 MU-MIMO, 2 spatial streams
• Flexible antenna ports
• External antenna
• Aironet 1562D
• 802.11ac Wave 2 support
• 2x2 MU-MIMO, 2 spatial streams
• Directional antenna
• 802.11ac Wave 1 and 2 capabilities
• 1562I: 3 x 3 MIMO with three spatial streams
• 1562E/D 2 x 2 MIMO with two spatial streams
• Multi and single user MIMO
• Maximal Ratio Combining (MRC)
• 802.11ac beamforming (transmit beamforming)
• 20-, 40-, and 80 MHz channels
• PHY data rates up to 1.3 Gbps (80 MHz in 5 GHz)
• Packet aggregation: A MPDU (Tx/Rx) and A MSDU (Tx/Rx)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11n (and related) capabilities
• 1562I: 3 x 3 MIMO with three spatial streams
• 1562E/D: 2 x 2 MIMO with two spatial streams
• MRC
• 20- and 40 MHz channels
• PHY data rates up to 450 Mbps
• Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
• 802.11 DFS
• CSD support
• Data rates supported
• 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
• 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
• Interfaces
• WAN port 10/100/1000BASE-T Ethernet, autosensing (RJ-45), PoE in
• SFP port (fiber or electrical)
• Management console port (RJ-45)
• Multicolor LED
• DC power input
• Reset button
• Uplink options
• Ethernet, SFP, and wireless mesh (future availability)
• Dimensions(L x W x D)
• 1562I: 9.0 x 6.8 x 3.9 in (22.9 x 17.1 x 9.8 cm)
• 1562D: 9.0 x 6.8 x 4.3 in (22.9 x 17.1 x 10.9 cm)
• 1562E:: 9.0 x 6.8 x 3.9 in (22.9 x 17.1 x 9.8 cm)
• Weight
• 1562I: 5.6 lb (2.5 kg)
• 1562D: 5.7 lb (2.6 kg)
• 1562E: 5.6 lb (2.5 kg)
• Warranty: 1 year limited hardware warranty

• Aironet 1542I
• Semi omnidirectional antenna
• 802.11ac Wave 2 support
• MU MIMO 2x2, 2 spatial streams
• Flexible deployment with Mobility Express
• as traditional APs, and in mesh networks
• Aironet 1542D
• Directional antenna
• 802.11ac Wave 2 support
• MU-MIMO 2x2, 2 spatial streams
• Flexible deployment with Mobility Express
• as traditional APs, and in mesh networks
• 802.11ac Wave 1 and 2 capabilities
• 1542I/D: 2 x 2 MIMO with two spatial streams
• Multiuser and single user MIMO
• Maximal Ratio Combining (MRC)
• 802.11ac beamforming (transmit beamforming)
• 20-, 40-, and 80-MHz channels
• PHY data rates up to 867 Mbps (80 MHz in 5 GHz)
• Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11n (and related) capabilities
• 1542I/D: 2 x 2 MIMO with two spatial streams
• MRC
• 20- and 40-MHz channels (40 MHz in 5 GHz)
• PHY data rates up to 300 Mbps
• Packet aggregation: A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
• 802.11 DFS
• CSD support
• Data rates supported: 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
• 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
• 802.11n data rates on 2.4 and 5 GHz
• Maximum conducted transmit power
• 1542I
• 2.4 GHz: 27 dBm with 2 antennas
• 5 GHz: 25 dBm with 2 antennas
• 1542D
• 2.4 GHz: 27 dBm with 2 antennas
• 5 GHz: 25 dBm with 2 antennas
• Interfaces
• WAN port 10/100/1000BASE-T Ethernet, autosensing (RJ-45), PoE in
• Management console port (RJ-45)
• Multicolor LED/Reset button
• Wireless Access
• 802.11i, Wi-Fi Protected Access 2 (WPA2), and WPA
• 802.1X authentication, including Extensible Authentication Protocol (EAP) and Protected EAP (EAP -PEAP), EAP Transport Layer Security (EAP-TLS), EAP-Tunneled TLS
• (EAP-TTLS), EAP-Subscriber Identity Module (EAP-SIM), and Cisco LEAP
• VPN pass-through
• IP Security (IPsec)
• Layer 2 Tunneling Protocol (L2TP)
• MAC address filtering
• Uplink options: Ethernet and wireless mesh
• Dimensions(L x W x H):
• 1542I/D: 7.9 x 5.9 x 2.4 in.(20 x 15 x 6.1 cm)
• Weight
• 1542I/D: 2.75 lb (1.25 kg)
• Warranty: 1 year limited hardware warranty

• Three radios: 2.4GHz (4x4), 5GHz (4x4), and BLE, Supports OFDMA and MU-MIMO, Internal and external antenna
• Software: Cisco Unified Wireless Network Software Release 8.9 or later
• Cisco IOS XE Software Release 16.11 or later
• Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
• Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
• 802.11n version 2.0 (and related) capabilities
• 4x4 MIMO with four spatial streams
• Maximal Ratio Combining (MRC)
• 802.11n and 802.11a/g beamforming
• 20- and 40-MHz channels
• PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11ac
• 4x4 downlink MU-MIMO with four spatial streams
• MRC
• 802.11ac beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• 802.11ax
• 4x4 downlink MU-MIMO with four spatial streams
• Uplink/downlink OFDMA
• TWT
• BSS coloring
• MRC
• 802.11ax beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• Integrated antenna: 2.4 GHz, peak gain 3 dBi, internal antenna, omnidirectional in azimuth
• 5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
• External antenna (sold separately)
• Cisco Catalyst 9115AXE Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
• Cisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety of deployment scenarios
• Interfaces: 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz
• Management console port (RJ-45), USB 2.0 (enabled via future software)
• Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
• Dimensions (W x L x H)
• Access point (without mounting brackets): C9115I: 8.0 x 8.0 x 1.5 in. (20.3 x 20.3 x 3.8 cm), C9115E: 8.0 x 8.0 x 1.7 in. (20.3 x 20.3 x 4.3 cm)
• Weight: Cisco Catalyst 9115AXI, 1.98 lb (0.9 kg)
• Cisco Catalyst 9115AXE, 2.43 lb (1.1 kg)
• System memory: 2048 MB DRAM, 1024 MB flash
• Warranty: Limited lifetime hardware warranty

• Three radios: 2.4GHz (4x4), 5GHz (8x8), and BLE, Supports OFDMA and MU-MIMO, Internal antenna
• Software: Cisco Unified Wireless Network Software Release 8.9 or later
• Cisco IOS XE Software Release 16.11 or later
• Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
• Cisco 3500, 5520, and 8540 Series Wireless Controllers, and Cisco Virtual Wireless Controller
• 802.11n version 2.0 (and related) capabilities
• 8x8 MIMO with four spatial streams for 5 GHz band
• 4x4 MIMO with four spatial streams for 2.4 GHz band
• Maximal Ratio Combining (MRC)
• 20- and 40-MHz channels
• PHY data rates up to 600 Mbps (40 MHz with 5 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• Cyclic Shift Diversity (CSD) support
• 802.11ac
• 8x8 downlink MU-MIMO with eight spatial streams
• MRC
• 802.11ac beamforming
• 20-, 40-, 80, and 160 MHz channels
• PHY data rates up to 3.5 Gbps at 5 GHz
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• CSD support
• 160 MHz support only on 4 spatial stream
• 802.11ax
• 8x8 MIMO with eight spatial streams for 5-GHz band
• 4x4 MIMO with four spatial streams for 2.4-GHz band
• Downlink OFDMA
• TWT
• MRC
• 802.11ax beamforming
• 20-, 40-, 80, and 160 MHz channels
• PHY data rates up to 5 Gbps at 5 GHz
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• CSD support
• Integrated antenna: 2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
• 5 GHz, peak gain 6 dBi, internal antenna, omnidirectional in azimuth
• Interfaces: 1x 100, 1000, 2500, 5000 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
• Management console port (RJ-45)
• USB 2.0 with up to 4.5W (enabled via future software)
• Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
• Dimensions (W x L x H)
• Access point (without mounting bracket and mounting features): 8.70 x 8.70 x 1.94 in. (22 x 22 x 4.93 cm)
• Access point (without mounting bracket): 8.70 x 8.70 x 2.19 in. (22 x 22 x 5.56 cm)
• Weight: 3.02 lb (1.4 kg)
• System memory: 2048 MB DRAM, 1024 MB flash
• Warranty: Limited lifetime hardware warranty

• Four radios: 2.4 GHz (4x4), 5 GHz (4x4), Cisco RF ASIC and BLE/IoT
• Cisco Flexible Radio Assignment and Cisco CleanAir Technology
• Internal and external antenna
• Software
• Cisco Unified Wireless Network Software Release 8.9.x or later
• Cisco IOS XE Software Release 16.11 with AP Device Pack, or later
• Supported wireless LAN controllers
• Cisco Catalyst 9800 Series Wireless Controllers
• Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
• 802.11n version 2.0 (and related) capabilities
• 4x4 MIMO with four spatial streams
• Maximal Ratio Combining (MRC)
• 802.11n and 802.11a/g beamforming
• 20- and 40-MHz channels
• PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11ac
• 4x4 downlink MU-MIMO with four spatial streams
• MRC
• 802.11ac beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• 802.11ax
• 4x4 downlink MU-MIMO with four spatial streams
• Uplink/downlink OFDMA
• TWT
• BSS coloring
• MRC
• 802.11ax beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• Interfaces: 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
• Management console port (RJ-45), USB 2.0 3.75W (enabled via future software)
• Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
• Dimensions (W x L x H)
• Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7 (21.6 x 21.6 x 4.3 cm), C9120E and C9120P: 8.5 x 8.05x 2.0 (21.6 x 21.6 x 5.1 cm)
• Weight: Cisco Catalyst 9120I, 2.87 lbs (1.3 kg)
• Cisco Catalyst 9120E/P, 3 lbs (1.36 kg)
• System memory: 2048 MB DRAM, 1024 MB flash
• Warranty: Limited lifetime hardware warranty

• Four radios: 2.4 GHz (4x4), 5 GHz (8x8 and 4x4), Cisco RF ASIC, and BLE/IoT
• Cisco Flexible Radio Assignment and Cisco CleanAir Technology
• Internal and external antenna
• WiFi 6 certified
• Software: Catalyst 9130 AXI: Cisco Unified Wireless Network Software Release 8.10.x or later
• Cisco IOS XE Software Release 16.12.1 with AP Device Pack, or later
• Catalyst 9130AXE: Cisco Unified Wireless Network Software Release 8.10MR1 or later
• Cisco IOS XE Software Release 17.1.1 s or later
• Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
• Cisco 3504, 5520, and 8540 Wireless Controllers and Cisco Virtual Wireless Controller
• 802.11n version 2.0 (and related) capabilities
• 4x4 MIMO with four spatial streams
• Maximal Ratio Combining (MRC)
• 802.11n and 802.11a/g
• 20- and 40 MHz channels
• PHY data rates up to 1.5 Gbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
• 802.11 Dynamic Frequency Selection (DFS)
• Cyclic Shift Diversity (CSD) support
• 802.11ac
• 8x8 downlink MU-MIMO with eight spatial streams
• MRC
• 802.11ac beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 6.9 Gbps (160 MHz with 5 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• WPA3 support
• 802.11ax
• 8x8 uplink/downlink MU-MIMO with eight spatial streams
• Uplink/downlink OFDMA
• TWT
• BSS coloring
• MRC
• 802.11ax beamforming
• 20-, 40-, 80-, and 160-MHz channels
• PHY data rates up to 10 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)
• Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
• 802.11 DFS
• CSD support
• WPA3 support
• System memory: 2048 MB DRAM, 1024 MB flash
• Interfaces
• 1x 100, 1000, 2500, 5000 Multigigabit Ethernet (RJ-45) – IEEE 802.3az
• Management console port (RJ-45)
• USB 2.0 at 4.5W (enabled via future software)
• Dimensions (W x L x H)
• Access point (without mounting brackets):
• C9130AXI: 8.9 x 8.9 x 1.88 in. (22.6 x 22.6 x 4.8 cm)
• C9130AXE: 9.17 x 9.17 x 1.58 in. (23.3 x 23.3 x 4.0 cm)
• Weight: Cisco Catalyst 9130AXI, 3.2 lb. (1.45 kg)
• Cisco Catalyst 9130AXE, 3.78 lb. (1.71 kg)
• Warranty: Limited lifetime hardware warranty

• Part: JL063A
• Device Type: Radio access point
• Form Factor: External
• Dual Radio
• RAM: 256 MB
• Flash Memory: 128 MB
• Frequency Band: 2.4 GHz, 5 GHz
• Interfaces    : 1 x 1000Base-T - RJ-45
• Radios (built-in) : 802.11a/b/g/n
• Antenna : Internal
• Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
• Key Features: Auto-uplink (auto MDI/MDI-X), IPv6 support, Wireless Distribution System (WDS) support
• MIMO technology, Spanning Tree Protocol (STP) support, IPv4 support, Encryption
• Limited Lifetime Warranty

• Part: J9799A
• Device Type: Radio access point
• Form Factor: External
• Frequency Band: 2.4 GHz, 5 GHz
• Interfaces    : 1 x 1000Base-T - RJ-45
• Radios (built-in) : 802.11a/b/g/n
• Antenna : Internal
• Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
• Key Features: Auto-uplink (auto MDI/MDI-X), IPv6 support, Wireless Distribution System (WDS) support
• MIMO technology, Spanning Tree Protocol (STP) support, IPv4 support
• Limited Lifetime Warranty

• Part: JL024A
• Ports and Slots : 1 RJ-45 autosensing 10/100/1000 port
• Radios (built-in) : 802.11a/b/g/n
• Antenna : Internal 2.4/5 GHz MIMO omni-directional antennas
• Number of internal antennas : 2
• Dual-band, Single-radio indoor device at 5 GHz or 2.4 GHz
• Form factor: External - Indoor
• PoE power : 7 W PoE
• DLP: IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n
• Key Features: Standalone, Auto-uplink (auto MDI/MDI-X) , IPv6 support , MIMO technology
• Spanning Tree Protocol (STP) support , Wireless Distribution System (WDS) support, Encryption
• Limited Lifetime Warranty

• Part: JW240A
• Device Type: Radio Access Point
• Radio: 802.11a/b/g/n/ac Dual Band
• Connectivity: Wireless
• Interfaces: 2 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x USB 2.0 - Type A
• Form factor: In-ceiling - Indoor
• Power Over Ethernet Supported (PoE+)
• Key Features: 3T3R MIMO technology , Adaptive Radio Management (ARM)
• Advanced Cellular Coexistence (ACC) , Auto-sensing per device
• Auto-uplink (auto MDI/MDI-X) , Cyclic Delay Diversity (CDD),Transmit Beam-forming (TxBF) ready
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
• Limited lifetime warranty


• Part: JW228A
• Device Type: Radio Access Point
• Radio: 802.11a/b/g/n/ac Dual Band
• Connectivity: Wireless
• Power Over Ethernet Supported (PoE+)
• Key Features: 3T3R MIMO technology , Adaptive Radio Management (ARM)
• Advanced Cellular Coexistence (ACC) , Auto-sensing per device
• Auto-uplink (auto MDI/MDI-X) , Cyclic Delay Diversity (CDD),Transmit Beam-forming (TxBF) ready
• DLP: IEEE 802.11a , IEEE 802.11ac , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n
• Limited lifetime warranty


• Part: JW212A
• Device Type: Radio Access Point
• Radio: 802.11a/b/g/n/ac, Dual Band
• Form factor: In-ceiling - Indoor
• Power Over Ethernet Supported (PoE+)
• Key Features: Auto-uplink (auto MDI/MDI-X), DFS support, Quality of Service (QoS)
• Trusted Platform Module (TPM), reset button, 2T2R MIMO technology, Adaptive Radio Management (ARM)
• Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD)
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
• Limited lifetime warranty


• Part: JW190A
• Device Type: Radio Access Point
• Radio: 802.11a/b/g/n
• Interfaces: 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x management
• Form factor: In-ceiling
• Power Over Ethernet Supported (PoE+)
• Key Features: Auto-uplink (auto MDI/MDI-X), DFS support, Trusted Platform Module (TPM), reset button
• 2T2R MIMO technology, Adaptive Radio Management (ARM), Maximum Ratio Combining (MRC), dual-band 802.11n, Low Density Parity Check (LDPC)
• Direct Sequence Spread Spectrum (DSSS), optimised for Microsoft Lync, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC)
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
• Limited lifetime warranty

• Part: J9693A
• Device Type: Radio Access Point
• Connectivity: Wireless
• Radio: 802.11a/n+802.11a/b/g/n
• Interfaces: 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x serial - console - RJ-45
• RAM: 256 MB SDRAM
• Flash Memory: 128 MB
• Form factor: External
• Power Over Ethernet Supported
• Key Features: Auto-sensing per device , Full duplex mode , Half duplex mode , Manageable , Quality of Service (QoS)
• DLP: IEEE 802.3 , IEEE 802.3ab , IEEE 802.3u
• Limited lifetime warranty


• Part: J9651A
• Device Type: Radio Access Point
• Connectivity: Wireless
• Radio: 802.11a/n+802.11a/b/g/n
• Antenna: (3) 5 dBi 2.4 GHz and (3) 7 dBi 5 GHz omnidirectional antennas
• Interfaces: 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x serial - console - RJ-45
• RAM: 256 MB SDRAM
• Flash Memory: 128 MB
• Form factor: External
• Power Over Ethernet Supported 12.9W
• Key Features: Auto-uplink (auto MDI/MDI-X), Intrusion Detection System (IDS)
• Intrusion Prevention System (IPS), Wi-Fi Multimedia (WMM) support
• Quality of Service (QoS), Multiple SSID support, IP address filtering
• Limited lifetime warranty

• Part: JG688A
• Device Type: Radio Access Point
• 1x RJ-45 10/100/1000 port,1x RJ-45 serial console port
• Radio: 802.11a/n, b/g/n
• Interfaces: 1 x 1000Base-T - RJ-45 ¦ 1 x management - RJ-45 ¦ 4 x aerial
• Form factor: Wall Mountable, Ceiling Mountable
• Model: IEEE 802.11n Wireless
• RAM: 128 MB
• Flash Memory: 128 MB
• PoE supported
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
• Key Features: Quality of Service (QoS), MIMO Technology, Encryption
• Network / Transport Protocol : DHCP
• Limited lifetime warranty


• Part: JG654A
• Device Type: Radio Access Point
• 1x RJ-45 10/100/1000 port
• 1x RJ-45 serial console port
• Radio: 802.11a/n, b/g/n
• Interfaces: 1 x 1000Base-T - RJ-45 ¦ 1 x management - RJ-45 ¦ 4 x aerial
• Form factor: Wall Mountable, Ceiling Mountable
• Model: IEEE 802.11n Wireless
• RAM: 128 MB
• Flash Memory: 128 MB
• PoE supported
• DLP: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
• Key Features: Quality of Service (QoS), MIMO Technology, Encryption
• Network / Transport Protocol : DHCP
• Limited lifetime warranty
