Zebronics ZEB PGP500W Power Supply
- Product Description:
- Active PFC: Yes
- Input voltage: 230v
- Input current: 3A
- Fan type: Oil bearing
- Power good signal: 300ms
- Hold up time: ≥18ms
- Efficiency: 20% loading ≥ 82%
- 50% loading ≥ 85%,
- 100% loading ≥ 82%
- MTBF: 20000 hours
- Protections: OVP / OPP / SCP / UVP
- Operating temp: 45ºc
- Dimension: 150 x 140 x 85 mm (W x D x H)
- Box dimension: 300 x 250 x 112 mm (W x D x H)
- Weight: 1.55 kg
- Warranty: 1 Year Warranty
Zebronics ZEB PGP600W Power Supply
- Product Description:
- Active PFC: Yes
- Input voltage: 230v
- Input current: 4A
- Fan type: Oil bearing
- Power good signal: ≥300ms
- Hold up time: ≥18ms
- Efficiency: 20% loading ≥ 82%
- 50% loading ≥ 85%,
- 100% loading ≥ 82%
- MTBF: 20000 hours
- Protections: OVP / OPP / SCP / UVP
- Operating temp: 45ºc
- Dimension: 150 x 140 x 85 mm (W x D x H)
- Box dimension: 300 x 247 x 112 mm (W x D x H)
- Weight: 1.6 kg
- Warranty: 1 Year Warranty
Zebronics ZEB PGP750W Power Supply
- Product Description:
- Active PFC: Yes
- Input voltage: 100-230v
- Input current: 12-6A
- Fan type: Oil bearing
- Power good signal: ≥300ms
- Hold up time: ≥18ms
- Efficiency: 20% loading ≥ 87%
- 50% loading ≥ 90%,
- 100% loading ≥ 87%
- MTBF: 20000 hours
- Protections: OVP / OPP / SCP / UVP
- Operating temp: 45ºc
- Dimension (W x D x H): 188 x 146 x 86 mm
- Box dimension (W x D x H): 330 x 196 x 130 mm
- Weight: 2.45 kg
- Warranty: 1 Year Warranty
