• GAMING HDD (with heatsink)
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:2TB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,400
• Sequential Write MB/s up to (Q=32, T=1):2,900
• Random Read 4KB IOPS up to (Q=32, T=8):480K
• Random Write 4KB IOPS up to (Q=32, T=8):550K
• Endurance (TBW):1200
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):100mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:24.2 ± 0.30mm
• Height:8.1mm
• Weight:33.2g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• With Heatsink model no:WDS200T3XHC-00SJG0

• GAMING HDD (with heatsink)
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:1TB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,470
• Sequential Write MB/s up to (Q=32, T=1):3,000
• Random Read 4KB IOPS up to (Q=32, T=8):515K
• Random Write 4KB IOPS up to (Q=32, T=8):560K
• Endurance (TBW):600
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):100mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:24.2 ± 0.30mm
• Height:8.1mm
• Weight:33.2g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• With Heatsink model no: WDS100T3XHC-00SJG0

• GAMING HDD (with heatsink)
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:500GB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,430
• Sequential Write MB/s up to (Q=32, T=1):2,600
• Random Read 4KB IOPS up to (Q=32, T=8):420K
• Random Write 4KB IOPS up to (Q=32, T=8):380K
• Endurance (TBW):300
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):70mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:24.2 ± 0.30mm
• Height:8.1mm
• Weight:33.2g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• With Heatsink model no: WDS500G3XHC-00SJG0

• GAMING HDD
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:2TB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,400
• Sequential Write MB/s up to (Q=32, T=1):2,900
• Random Read 4KB IOPS up to (Q=32, T=8):480K
• Random Write 4KB IOPS up to (Q=32, T=8):550K
• Endurance (TBW):1200
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):100mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:22 ± 0.15mm
• Height:2.38mm
• Weight:7.5g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• Without Heatsink model no: WDS200T3X0C-00SJG0

• GAMING HDD
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:1TB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,430
• Sequential Write MB/s up to (Q=32, T=1):3,000
• Random Read 4KB IOPS up to (Q=32, T=8):515K
• Random Write 4KB IOPS up to (Q=32, T=8):560K
• Endurance (TBW):600
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):100mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:22 ± 0.15mm
• Height:2.38mm
• Weight:7.5g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• Without Heatsink model no: WDS100T3X0C-00SJG0

• GAMING HDD
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:500GB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,430
• Sequential Write MB/s up to (Q=32, T=1):2,600
• Random Read 4KB IOPS up to (Q=32, T=8):420K
• Random Write 4KB IOPS up to (Q=32, T=8):380K
• Endurance (TBW):300
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):70mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:22 ± 0.15mm
• Height:2.38mm
• Weight:7.5g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• Without Heatsink model no: WDS500G3X0C-00SJG0

• GAMING HDD
• Specifications:
• Interface:PCIe Gen3 8Gb/s, up to 4 lanes
• Formatted Capacity:250GB
• Performance:
• Sequential Read MB/s up to (Q=32, T=1):3,100
• Sequential Write MB/s up to (Q=32, T=1):1,600
• Random Read 4KB IOPS up to (Q=32, T=8):220K
• Random Write 4KB IOPS up to (Q=32, T=8):180K
• Endurance (TBW):200
• Power:
• Peak Power (10us):2.8A
• PS3 (low power):70mW
• Sleep (PS4) (low power):2.5mW
• Reliability:
• MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)
• Environmental:
• Operating Temperature:32oF to 158oF (0oC to 70oC)
• Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)
• Physical Dimensions - M.2 2280
• Form Factor:M.2 2280-S3-M
• Length:80 ± 0.15mm
• Width:22 ± 0.15mm
• Height:2.38mm
• Weight:7.5g ± 1g
• Limited Warranty:5 years Warranty
• Ordering Information:
• Without Heatsink model no: WDS250G3X0C-00SJG0

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 5400 RPM
• model no:WD60PURZ
• capcity:6TB
• Cache:64mb
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 5400 RPM
• model no:WD40PURZ
• capacity:4TB
• Cache:64mb
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 5400 RPM
• model no:WD30PURZ
• capacity:3TB
• Cache:64mb
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 5400 RPM
• model no:WD20PURZ
• capacity:2TB
• Cache:64mb
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 5400 RPM
• model no:WD10PURZ
• capcaity:1TB
• Cache:64mb
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 7200 RPM
• model:WD140PURZ
• capciy:14TB
• Cache:512
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 7200 RPM
• model:WD121PURZ
• capcity:12TB
• Cache:256
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 7200 RPM
• capcity:10tb
• model:WD101PURZ
• Cache:256
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 7200 RPM
• model:WD102PURZ
• capacity:10TB
• Cache:256
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Form Factor:3.5
• Interface:SATA 6Gb/s
• wd purple 7200 RPM
• model no:WD82PURZ
• capacity:8TB
• Cache:256
• Height (in./mm, max) 1.028/26.1
• Length (in./mm, max) 5.787/147
• Width (in./mm, ± .01 in.) 4/101.6
• Limited Warranty:3 years Warranty

• Features
• Capacity:1tb-14TB
• 1TB:WD10EFRX (CMR)
• 2TB:WD20EFAX (SMR)WD20EFRX (CMR)
• 3TB:WD30EFAX (SMR)WD30EFRX (CMR)
• 4TB:WD40EFAX (SMR)WD40EFRX (CMR)
• 6TB:WD60EFAX (SMR)WD60EFRX (CMR)
• 8TB:WD80EFAX (CMR)WD8003FFBX (CMR)
• 10TB:WD100EFAX (CMR)WD101EFAX (CMR)
• 12TB:WD120EFAX (CMR)
• 14TB:WD140EFAX (CMR)
• Form Factor:3.5inch
• Rotational speed (RPBM):5400
• Interface:SATA 6GB/s
• Limited Warranty:3 years

• Capacity:500GB-4TB
• Form Factor:2.5” /7mm
• Interface:SATA 6 Gb/s
• Limited Warranty:5 Years
• Model Numbers:500GB:WDS500G1R0A
• 1TB:WDS100T1R0A
• 2TB:WDS200T1R0A
• 4TB:WDS400T1R0

Product Specification
Capacity:7.6TB
Model Number:WDS768T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):1.8K
Read IOPS (max, Rnd 4KiB):467K
Write IOPS (max, Rnd 4KiB):65K
Mixed IOPS (max, 70/30 R/W, 4KiB):187K
Latency (μs, 4KiB Random Read QD1, 99%):225
Maximum Petabytes Written:11.21

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Product Specification
Capacity:3.84TB
Model Number:WWDS384T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):1.8K
Read IOPS (max, Rnd 4KiB):469K
Write IOPS (max, Rnd 4KiB):63K
Mixed IOPS (max, 70/30 R/W, 4KiB):174K
Latency (μs, 4KiB Random Read QD1, 99%):221
Maximum Petabytes Written:5.61

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Product Specification
Capacity:1.92TB
Model Number:WDS192T1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3.1K
Write Throughput (max MiB/s, Seq 128KiB):2K
Read IOPS (max, Rnd 4KiB):472K
Write IOPS (max, Rnd 4KiB):63K
Mixed IOPS (max, 70/30 R/W, 4KiB):194K
Latency (μs, 4KiB Random Read QD1, 99%):208
Maximum Petabytes Written:2.8

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

Product Specification
Capacity:96TB
Model Number:WDS960G1D0D
Security Encryption:No
Form Factor:U.2
Interface:PCIe Gen 3.1 x4
NVMe Specification (Complaint):1.3
Endurance:Endurance (Drive writes per day, DW/D):0.8

Performance
Read Throughput (max MiB/s, Seq 128KiB):3K
Write Throughput (max MiB/s, Seq 128KiB):1.1K
Read IOPS (max, Rnd 4KiB):413K
Write IOPS (max, Rnd 4KiB):44K
Mixed IOPS (max, 70/30 R/W, 4KiB):111K
Latency (μs, 4KiB Random Read QD1, 99%):210
Maximum Petabytes Written:1.4

Reliability
MTBF (M hours):2
Uncorrectable Bit Error Rate (UBER):1 in 10
Limited Warranty (yrs):5

Power Management:
Requirement (DC +/- 10%):+12V
Operating Modes (W, Average):10, 11, 12
Idle (W, average):4.6

Physical Size
z-height (mm):7.00 +0.2/-0.5 (including labels)
Dimensions (width x length, mm):69.85 (+/- 0.25) x 100.45
Weight (g, max):95

Environmental

Operating Temperature:0°C to 70°C
Non-operating Temperature:-40°C to 85°C

• WD 3.5 INCH,
• Capacity:500GB - 6TB
• Interface:SATA 6Gb/s
• Limited Warranty:5 years
• RPM Class:7200
• Model Numbers:  500gb:WD5003AZEX (CMR)
• 1TB:WD1003FZEX (CMR)
• 2TB:WD2003FZEX (CMR)
• 4TB:WD4005FZBX (CMR)
• 6TB:WD6003FZBX (CMR)
• colour: black

• WD 2.5 INCH,9.5MM
• Capacity:1TB
• Interface:SATA 6Gb/s
• Limited Warranty:5 years
• RPM Class:7200
• Model Numbers:WD10SPSX (SMR)
• colour: black

• WD 2.5 INCH,7MM
• Capacity:250GB - 500GB
• Interface:SATA 6Gb/s
• Limited Warranty:5 years
• RPM Class:7200
• Model Numbers:250GB WD2500LPLX (CMR)
• 320GB: WD3200LPLX (CMR)
• 500GB:WD5000LPLX (CMR)
• colour: black

Formatted Capacity:2TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW):1200

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS200T3XHC-00SJG0

Formatted Capacity:1TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,470
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS100T3XHC-00SJG0

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS500G3XHC-00SJG0

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance :
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW):300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature:32oF to 158oF (0oC to 70oC)
Non-operating Temperature:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M with Heatsink
Length:80 ± 0.15mm
Width:24.2 ± 0.30mm
Height:8.1mm
Weight:33.2g ± 1g

Ordering Information:
With Heatsink:WDS500G3XHC-00SJG0

Formatted Capacity:2TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,400
Sequential Write MB/s up to (Q=32, T=1):2,900
Random Read 4KB IOPS up to (Q=32, T=8):480K
Random Write 4KB IOPS up to (Q=32, T=8):550K
Endurance (TBW)1,200

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS200T3X0C-00SJG0

Formatted Capacity:1TB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):3,000
Random Read 4KB IOPS up to (Q=32, T=8):515K
Random Write 4KB IOPS up to (Q=32, T=8):560K
Endurance (TBW):600

Power:
Peak Power (10us):2.8A
PS3 (low power):100mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS100T3X0C-00SJG0

Formatted Capacity:500GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,430
Sequential Write MB/s up to (Q=32, T=1):2,600
Random Read 4KB IOPS up to (Q=32, T=8):420K
Random Write 4KB IOPS up to (Q=32, T=8):380K
Endurance (TBW)4:300

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS500G3X0C-00SJG0

Formatted Capacity:250GB

Interface:PCIe Gen3 8Gb/s, up to 4 lanes

Performance 2:
Sequential Read MB/s up to (Q=32, T=1):3,100
Sequential Write MB/s up to (Q=32, T=1):1,600
Random Read 4KB IOPS up to (Q=32, T=8):220K
Random Write 4KB IOPS up to (Q=32, T=8):180K
Endurance (TBW)4:200

Power:
Peak Power (10us):2.8A
PS3 (low power):70mW
Sleep (PS4) (low power):2.5mW

Reliability:
MTTF6:1,750,000 hours (Telcordia SR-332, GB, 40oC)

Environmental:
Operating Temperature7:32oF to 158oF (0oC to 70oC)
Non-operating Temperature8:-67oF to 185oF (-55oC to 85oC)

Limited Warranty:5 years

Physical Dimensions - M.2 2280
Form Factor:M.2 2280-S3-M
Length:80 ± 0.15mm
Width:22 ± 0.15mm
Height:2.38mm
Weight:7.5g ± 1g

Ordering Information:
Without Heatsink: MODEL NO: WDS250G3X0C-00SJG0
